Pedrollo Centrifugal Pump F 65/125C – 5.5 kW, 3-Phase

ReflowX SKU: REF-7234

Product Details

Quantity

10
Availability (Lead Time)

6-10 Weeks
Product Location

United Arab Emirates
Condition

New
OEM

Italy
Equipment code

CFIHOS-30000550

Get Quotation Whatsapp Chat With Seller

Short Description

Pedrollo F 65/125C centrifugal pump, 5.5 kW, IE3 efficiency, suitable for high-flow water transfer in industrial applications.

Description

Specifications

– Brand: Pedrollo
– Model: F 65/125C
– Flow Rate: 600–1800 L/min
– Head: 16–11 m
– Power: 5.5 kW / 7.5 HP
– Voltage: 220–230V / 380–400V
– Frequency: 50 Hz
– Speed: 2900 RPM
– Phase: 3
– Protection Class: IP55
– Insulation Class: F
– Efficiency Class: IE3
– Max Temperature: 90°C
– Made in Italy
– Condition: Used

For further specifications or to inquire about this equipment and ReflowX's logistics services, please contact ReflowX at info@reflowx.com.

Technical Details

ISO 15926 Pt 4	7985
PCA RDS Code	RDS327239
CFIHOS ID	CFIHOS-30000550
IFC Class	IfcPump
Lower Limit Operating Temperature	+5°C
Operation Continuous Intermittent	Continuous
Upper Limit Operating Temperature	+90°C
Test Medium	Clean Water
Test Pressure	6 bar
Normal Operating Inlet Pressure	1.0 bar
Normal Operating Inlet Temperature	30°C
Normal Operating Outlet Pressure	1.6 bar
Orientation	Horizontal
Upper Limit Design Pressure	6 bar
UNSPSC Code	40151500
Upper Limit Design Temperature	+95°C
Upper Limit Operating Temperature	+90°C
Lower Limit Ambient Operating Temperature	-10°C
Lower Limit Design Temperature	0°C
Lower Limit Operating Inlet Pressure	0.5 bar
Lower Limit Operating Outlet Pressure	1.1 bar
Lower Limit Operating Volume Flow Rate	600 L/min (36 m³/h)
Pump Type	Centrifugal Pump
Upper Limit Ambient Operating Temperature	+50°C
Upper Limit Operating Inlet Pressure	4.0 bar
Upper Limit Operating Outlet Pressure	2.0 bar
Upper Limit Operating Volume Flow Rate	1800 L/min (108 m³/h)

General Terms

ReflowX and the seller retain the right to evaluate and approve offers.
Buyers should verify quantities and conditions upon delivery.
After successful engagement, both buyer and seller manage communication for payment terms and delivery schedule.
All parties agree to adhere to ReflowX Terms and Conditions in transactions.
Buyers can request value-added services such as pre-purchase inspections, Expediting & Delivery Services through ReflowX. Contact us!
