| Model Number
|
QXS.32
|
|---|---|
| ISO 15926 Pt 4
|
7985
|
| PCA RDS Code
|
RDS327239
|
| CFIHOS ID
|
CFIHOS-30000550
|
| IFC Class
|
IfcPump
|
| Lower Limit Operating Temperature
|
-10°C
|
| Operation Continuous Intermittent
|
Continuous
|
| Upper Limit Operating Temperature
|
+120°C
|
| Test Medium
|
Water
|
| Test Pressure
|
35.0 bar
|
| Normal Operating Inlet Pressure
|
1.0 bar
|
| Normal Operating Inlet Temperature
|
30°C
|
| Normal Operating Outlet Pressure
|
23.5 bar
|
| Orientation
|
Horizontal Baseplate-Mounted
|
| Upper Limit Design Pressure
|
25.0 bar
|
| UNSPSC Code
|
40151500
|
| Upper Limit Design Temperature
|
+130°C
|
| Upper Limit Operating Temperature
|
+120°C
|
| Lower Limit Ambient Operating Temperature
|
-10°C
|
| Lower Limit Design Temperature
|
-10°C
|
| Lower Limit Operating Inlet Pressure
|
0.5 bar
|
| Lower Limit Operating Outlet Pressure
|
1.5 bar
|
| Lower Limit Operating Volume Flow Rate
|
150 m³/h
|
| Pump Type
|
Centrifugal
|
| Upper Limit Ambient Operating Temperature
|
+50°C
|
| Upper Limit Operating Inlet Pressure
|
5.0 bar
|
| Upper Limit Operating Outlet Pressure
|
25.0 bar
|
| Upper Limit Operating Volume Flow Rate
|
1273 m³/h
|
×
