Jet-Lube Z-60™ Tool Joint Compound – 40 LB (Smooth Grey Paste)

Jet-Lube Z-60™ Tool Joint Compound is a premium-grade, non-plating thread compound engineered with 60% metallic zinc and refined low sulfur oil. It meets API Bulletin 5A2 requirements and is designed to protect tool joint threads and shoulders in demanding drilling operations.

The compound forms a durable, smooth grey paste that offers strong adhesion to wet surfaces, high load-bearing performance, and excellent resistance to corrosion and galling. Z-60™ performs reliably across a wide temperature range and ensures consistent makeup torque, making it ideal for harsh service environments.

Specifications:

– Product Number: 20713
– Weight: 40 Lbs
– Packaging: Pail
– Base Materials: Aluminum Complex / Petroleum
– Color / Appearance: Smooth Grey Paste
– Service Rating: 0°F to 300°F / -18°C to 150°C
– Friction Factor: 1.0
– Penetration @77°F (ASTM D-217): 275–305
– Flash Point (ASTM D-92): >430°F (221°C)
– Density: 12.314 lbs/gal
– Copper Strip Corrosion: 1A
– 4-Ball Weld Point (ASTM D-2596): 500 kgf
– Oil Separation: <5.0%
– VOC Content: 0 g/L

Stock Quantity & Date of Manufacture:
– 125 Pails available
– Manufactured on: 19/09/2019

For further specifications or to inquire about this equipment and ReflowX's logistics services, please contact ReflowX at info@reflowx.com
