Solar Titan 130 SoLoNOx — 2 × 15 MW / 14.9 MVA Gas-Turbine Generator Packages (NEW 2017)
Snapshot
A matched pair of brand-new, zero-hour Solar Turbines Titan 130 packages equipped with SoLoNOx® dry-low-emissions combustion. Each set is rated ≈ 15 MW electrical (16.5 MW ISO shaft power), configured for 10.5 kV, 50 Hz service and supplied with variable-frequency AC-motor start. Units are crated indoors in China and offered FOB Shanghai for immediate export.
Key Technical Data
| Item | Value | |
|---|---|---|
| ISO shaft output | 16 529 kW (≈ 16.5 MW) | |
| Generator rating | 10.5 kV, 50 Hz, 0.85 PF | |
| Gearbox speed | 1 500 rpm, 50 Hz | |
| Combustion | SoLoNOx® DLE (≤ 15 ppm NOₓ on gas) | |
| Start system | Variable-Frequency Drive (VFD) motor start | |
| Package footprint (L × W × H) | 19.0 m × 5.3 m × 10.5 m | |
| Transport weight | ≈ 105 t each |
Scope of Supply (per unit)
Titan 130 gas-turbine skid with welded base and elastic mounts.
Dry-low-emission SoLoNOx combustor for natural-gas operation; diesel retrofit optional.
1500 rpm reduction gearbox for direct coupling to generator or mechanical load.
Brushless synchronous generator (10.5 kV, air-cooled).
AC-motor VFD starter and twin 112 kW motors for reliable black-start capability scope of supply.
Integrated auxiliaries – dual lube-oil systems, gas-fuel skid, CO₂ fire-protection, on-line/off-line water-wash cart.
Weather-proof acoustic enclosure, ≤ 85 dB(A) at 1 m, with ventilation and lighting.
Operator station (TT4000) & Turbotronic control cabinet with remote interface.
Full OEM documentation, factory test certificates, random spare-parts kit and special tools.
Condition & Logistics
Year of manufacture: 2017 | Operating hours / starts: 0 h / 0
Quantity available: 2 identical units (can be sold singly or as a set).
Location: Bonded warehouse, Shanghai, China — virtual or on-site inspection possible.
Incoterm: FOB Shanghai Port — ready to ship within 4 weeks of contract signing.
Pricing
$30,000,000 EXW China
Contact
Message via ReflowX for further information rfq@reflowx.com +971 50 384 6311
Technical Details
| Model Number | Titan130 |
|---|---|
| Year of Manufacturing | 2017 |
| Manufacturer Name | Solar |
