2-Piece Flanged Ball Valve (NSW) – DN15 to DN200, Class 150/300, Full Port

Product Details

Quantity

500
Availability (Lead Time)

4-6 Weeks
Product Location

China
Condition
OEM

WENZHOU NEWSWAY VALVE CO. LTD
Equipment code

Get Quotation Whatsapp

Short Description

High-performance 2-piece flanged ball valve, DN15–DN200 (½"–8"), with full port floating ball design, ANSI/DIN/JIS standards, ISO 5211 mounting pad, and fire-safe construction per API 6FA/API 607.

Description

2-Piece Flanged Ball Valve (NSW) – DN15 to DN200, Class 150/300, Full Port

Long Description:
The NSW 2-piece flanged ball valve is designed for efficient, leak-proof flow control in demanding industrial systems. With sizes ranging from DN15 to DN200 (½" to 8") and pressure class options including ANSI 150/300, DIN PN16–40, and JIS 10K, this valve is suitable for a wide range of international applications.

Engineered with a floating ball and full port configuration, the valve ensures minimal pressure drop and maximum flow efficiency. Manufactured from premium materials such as WCB carbon steel, CF8/CF8M stainless steel, CF3/CF3M low-carbon variants, and duplex stainless steel, the valve body and components are cast using the precision silica sol investment process for durability and dimensional accuracy.

Specifications:

– Valve Type: 2-Piece Flanged Ball Valve
– Design: Floating Ball, Full Port
– Sizes Available: DN15 to DN200 (½" to 8")
– Pressure Ratings:
• ANSI: Class 150, 300
• DIN: PN16, PN25, PN40
• JIS: 10K
– Temperature Range: -20°C to +200°C (-4°F to +392°F)
– Body Materials:
• WCB
• CF8 (304 SS), CF8M (316 SS)
• CF3 (304L SS), CF3M (316L SS)
• Duplex Stainless Steel
– Face-to-Face Standards: ANSI B16.10, DIN 3202 F1/F4/F5, GB/T 12221, JIS B2002
– End Connections:
• Flanged: ANSI B16.5, DIN 2632–2635, JB/T 79, JIS B2212
• Socket Weld: ASME B16.11
• Butt Weld: ASME B16.25
• Threaded: ANSI B1.20.1
– Thread Options: BSPP, BSPT, NPT, DIN 2999–259, ISO 228-1
– Testing & Inspection: MSS SP-100, EN 12266, API 598, ISO 5208
– Fire Safe Design: API 6FA, API 607
– Corrosion Compliance (Optional): NACE MR-0175, MR-0103, ISO 15848
– Additional Tests: PMI, UT, RT, PT, MT

For further specifications or to inquire about this equipment and ReflowX's logistics services, Please contact ReflowX at info@reflowx.com
