2" Flow Indicator – Paddlewheel Type, CF8M Stainless Steel, Class 150 RF Flanged

This 2" (DN50) flow indicator is a durable, two-way inline monitoring device that provides real-time visual confirmation of fluid movement using a rotating paddlewheel mechanism. The rotating paddlewheel, housed behind a clear, impact-resistant window, allows easy verification of flow direction and rate at a glance—ideal for confirming proper system operation.

Engineered with a corrosion-resistant CF8M stainless steel body (ASTM A351 equivalent to 316 SS), the unit is suited for use in aggressive chemical, water treatment, and general industrial applications. The raised face (RF) flanged ends conform to ANSI B16.5 Class 150 standards for seamless integration into standard piping systems. Pressure and temperature tolerances support up to 19 bar (275 psi) and 200°C, making it suitable for a wide range of operating environments.

Tested per API 598 standards, the unit ensures robust sealing integrity and reliable performance under fluctuating conditions. Its compact face-to-face dimension (~203 mm) and standard bolt pattern make it easy to install and maintain.

Specifications:

– Configuration: 2-Way Flow Indicator
– Flow Visualization: Rotating Paddlewheel (behind sight window)
– Nominal Diameter: 2" (DN50)
– Connection Type: 150# RF (Raised Face) Flanged Ends
– Flange Standard: ANSI B16.5
– Pressure Rating: Class 150 (PN20)
– Design Pressure: Up to 19 bar (275 psi)
– Temperature Rating: Typically up to 200°C
– Body Material: CF8M (ASTM A351 Grade Stainless Steel)
– Window Material: Clear impact-resistant window
– Face-to-Face Length: ~203 mm
– Flange Outside Diameter: 152 mm
– Bolt Circle Diameter (BCD): 120.7 mm
– Number of Bolts: 4
– Bolt Size: 5/8"-11 UNC
– Test & Inspection Standard: API 598
– Flow Direction: Bidirectional
– Application: Inline visual flow confirmation
– Availability: Available upon request

For further specifications or to inquire about this equipment and ReflowX's logistics services, Please contact ReflowX at info@reflowx.com
