3" Globe Valve, ANSI 1500, WCB Forged Body

ReflowX SKU: REF-2096

Product Details

Quantity

6
Availability (Lead Time)

0-2 Weeks
Product Location

United Arab Emirates
Condition

Surplus
OEM

YGG (logo visible)
Equipment code

Get Quotation Whatsapp Chat With Seller

Share on Facebook

Share on Twitter

Share on LinkedIn

Short Description

Type: Globe Valve Size: 3 Inch Pressure Class: ANSI 1500 (1500 psi)

Description

General Information

Type: Globe Valve

Size: 3 Inch (DN80)

Pressure Class: ANSI 1500 (1500 psi, approx. 103 bar)

Material: WCB (ASTM A216 Grade WCB – Cast Carbon Steel)

Body Type: Forged

Body Marking: "3 1500 WCB FORGED" – Indicates nominal diameter, pressure class, material, and forging method

Design and Construction

Valve Design:
Globe valve design provides efficient regulation of flow. Suitable for throttling and precise flow control.

End Connections:
Flanged (ANSI B16.5 or custom flange ratings)

Body Construction:
Forged, providing high strength and resistance to stress, ensuring durability and reliability in high-pressure applications.

Stem Type:
Rising Stem – The position of the stem indicates the valve’s open/closed position.

Seat Material:
Stainless steel or hard-facing material (depending on application requirements) to ensure longevity and resistance to wear.

Trim Type:
Generally, hardened stainless steel or similar corrosion-resistant material for trims to withstand high temperatures and pressure.

Pressure and Temperature Ratings

Pressure Class:
ANSI 1500 (1500 psi / 103 bar)

Temperature Range:
Typically ranges from -29°C to 425°C (-20°F to 800°F), depending on trim material, application, and service conditions.

Maximum Allowable Operating Pressure (MAOP):
1500 psi (103 bar)

Design Standard Compliance:
ANSI B16.34 – Design and testing standards for valves.
API 602 – For forged steel valves.
ASME B16.5 – Flange standards.

Flow and Operation

Flow Characteristics:
Equal percentage or linear characteristic for throttling control.

Valve Travel:
Full travel from fully closed to fully open (typically around 360° rotation).

Operation Type:
Manual or actuated (pneumatic/electric/hydraulic actuator as required).

Leakage Class:
ANSI/FCI 70-2 Class VI (or as required by application), offering low leakage to ensure tight sealing in service.

Materials and Compatibility

Valve Body Material:
Cast Carbon Steel – ASTM A216 WCB provides excellent strength and hardness, suited for high-pressure and moderate temperature applications.

Seat & Trim Material:
Stainless Steel or Hard-Faced Material (depending on application) to enhance resistance to erosion and wear.

Fluid Compatibility:
Suitable for a wide range of fluids including steam, natural gas, oil, water, chemicals, and condensates.

Key Performance Characteristics

Nominal Diameter:
3 Inches (DN80)

Flow Capacity:
Calculated based on valve size and pressure class, suitable for large flow rates with minimal restriction.

Valve Actuation Type:
Manual, Pneumatic, Electric, or Hydraulic.

Position Indication:
Typically via stem position indicator or actuator feedback.

For further specifications or to inquire about this equipment and ReflowX's logistics services, Please contact ReflowX at info@reflowx.com

Technical Details

ISO 15926 Pt 4	10554
ISO 15926 Pt 4	10554
PCA RDS Code	RDS292589
CFIHOS ID	CFIHOS-30000660
IFC Class	IfcValve
Design Specification	ASTM A216 Grade WCB
Fluid Name	Oil, Gas, Steam, Water, and Chemical Fluids
Full Opening Valve	Full Bore
Nominal Diameter	3 Inch (DN 80)
Normal Operating Pressure	1500 psi
Normal Operating Temperature	-29°C to 425°C
Piping Class	Class 1500 or ANSI B16.5
UNSPSC Code	40141600

General Terms

ReflowX and the seller retain the right to evaluate and approve offers.
Buyers should verify quantities and conditions upon delivery.
After successful engagement, both buyer and seller manage communication for payment terms and delivery schedule.
All parties agree to adhere to ReflowX Terms and Conditions in transactions.
Buyers can request value-added services such as pre-purchase inspections, Expediting & Delivery Services through ReflowX. Contact us!
