3DV Gate Valves – ½” to 10”

ReflowX SKU: REF-3444

Product Details

Quantity

50
Availability (Lead Time)

0-2 Weeks
Product Location

United Arab Emirates
Condition

New
OEM

3DV Valves, USA
Equipment code

Get Quotation Whatsapp

Short Description

Heavy-duty 3DV gate valves from the USA, available in ½” to 10” sizes and Class 150/300. Built with CF3M, CF8M, DI, or WCB body and CF8M disc, with RF, wafer, or lug connections.

Description

3DV Gate Valves – ½” to 10”, USA

3DV gate valves are industrial-grade shutoff valves engineered for on/off flow control in a wide range of fluid systems. Manufactured in the USA, these valves are available in sizes from ½” to 10” and in ANSI pressure classes 150 and 300. Designed with durable body materials including CF3M, CF8M, ductile iron (DI), and WCB carbon steel, they provide strength and corrosion resistance for critical service conditions. Each valve incorporates a stainless steel CF8M gate (disc) for long-lasting sealing performance. With end connection options including raised face (RF), wafer, or lug types, 3DV gate valves integrate easily into standard piping systems. Ideal for oil, gas, petrochemical, and water service lines.

Specifications:

– Manufacturer: 3DV Valves, USA
– Product Type: Gate Valve
– Size Range: ½” to 10”
– Pressure Ratings:
• Class 150
• Class 300
– Body Materials:
• CF3M (316L Stainless Steel)
• CF8M (316 Stainless Steel)
• DI (Ductile Iron)
• WCB (Carbon Steel)
– Disc/Gate Material:
• CF8M Stainless Steel
– End Connections:
• RF (Raised Face Flanged)
• Wafer type
• Lug type
– Design Features:
• Rising stem design
• Outside screw and yoke (OS&Y)
• Full port opening for minimal pressure drop
• Backseat design for stem packing isolation
• Bolted bonnet construction
– Operation:
• Handwheel
• Gear operator
• Electric or pneumatic actuators (optional)
– Standards & Testing:
• API 600 / API 603 (as applicable)
• API 598 (testing)
• ASME B16.34
• ISO 9001 manufacturing
For further specifications or to inquire about this equipment and ReflowX's logistics services, Please contact ReflowX at info@reflowx.com

Technical Details

ISO 15926 Pt 4	10554
Model Number	Gate Valve
Manufacturer Name	3DV Valves, USA
Height	180 mm to 1000 mm
Width	90 mm to 445 mm
Length	108 mm to 533 mm
Weight	5 kg to 250 kg
ISO 15926 Pt 4	10554
PCA RDS Code	RDS292589
CFIHOS ID	CFIHOS-30000660
IFC Class	IfcValve
Design Specification	ASME B16.34 (Pressure-Temperature Ratings)
Failure Action	Manual: Remains in last position
Fluid Name	Suitable for water, oil, gas (WOG), steam, air, and general industrial liquids or gases
Full Opening Valve	Yes – Full port design for minimal flow restriction
Nominal Diameter	½” to 10”
Normal Operating Pressure	19.6 bar to 51 bar
Normal Operating Temperature	-29°C to +200°C
Piping Class	ASME Class 150 and 300
UNSPSC Code	40141600
