Industrial Angle Valves – ½” to 12”, Cast Iron/Steel/SS, Threaded/Flanged Ends

ReflowX SKU: REF-7685

Product Details

Quantity

200
Availability (Lead Time)

6-10 Weeks
Product Location

United Arab Emirates
Condition

New
OEM

USA, Singapore, India, China, Korea
Equipment code

Get Quotation Whatsapp

Short Description

High-performance industrial angle valves available in sizes from ½” to 12”, built from cast iron, steel, brass/bronze, or stainless steel. Offered with threaded, socket weld, or flanged ends, and suitable for pressures up to 1000 PSI.

Description

Industrial Angle Valves – ½” to 12”, Cast Iron/Steel/SS, Threaded/Flanged Ends

These industrial angle valves are engineered for reliable control and shut-off applications across water, steam, oil, and gas systems. Manufactured in compliance with JIS, DIN, and ANSI standards, the valves are available in a variety of materials including cast iron, cast steel, forged steel, stainless steel (SS304/316), and brass/bronze. Available sizes range from ½” to 12”, with pressure ratings including PN10, PN16, JIS 5K/10K, and ANSI Class 150 to Class 900, as well as special ratings up to 1000 PSI. Connection types include NPT threaded, socket weld, and flanged ends to suit diverse piping systems. These valves are widely used in industrial, HVAC, marine, and utility piping systems and are sourced from trusted manufacturers across the USA, Singapore, India, China, and Korea.

Specification:

– Product Type: Industrial Angle Valves
– Material:
• Cast Iron
• Cast Steel
• Brass/Bronze
• Forged Steel
• Stainless Steel (SS304, SS316)
– Size Range: ½” to 12”
– Pressure Ratings:
• PN Ratings: PN10, PN16
• JIS Ratings: 5K, 10K
• ANSI Ratings: CL150, CL200, CL900
• Special: Up to 1000 PSI
– Standards: JIS, DIN, ANSI
– End Connections:
• NPT Threaded
• Socket Weld
• Flanged
– Surface Finish:
• Painted (cast iron/steel)
• Machined or polished (bronze/SS)
– Typical Applications:
• Steam & condensate control
• HVAC and building systems
• Marine & offshore piping
• Oil & gas distribution
• Process plant piping
– Origin: USA, Singapore, India, China, Korea

For further specifications or to inquire about this equipment and ReflowX's logistics services, Please contact ReflowX at info@reflowx.com

Technical Details

ISO 15926 Pt 4	10554
Height	120 mm to 650 mm
Width	75 mm to 500 mm
Length	90 mm to 400 mm
Weight	2 kg to 110 kg
ISO 15926 Pt 4	10554
PCA RDS Code	RDS292589
CFIHOS ID	CFIHOS-30000660
IFC Class	IfcValve
Failure Action	Last set position
Fluid Name	Water, Steam, Oil and petroleum-based fluids, Air
Full Opening Valve	Yes
Nominal Diameter	½” (DN15) to 12” (DN300)
Normal Operating Pressure	Up to 1000 PSI
Normal Operating Temperature	-10°C to +200°C
Piping Class	Class 150 to 900
UNSPSC Code	40141600
