Product Description:

Overview:

This 12" 150LBS 3PCS Trunnion Mounted Ball Valve is manufactured in compliance with API 6D standards and made from A182 F316 stainless steel, offering excellent corrosion resistance and durability for high-pressure applications. The valve features a fixed ball design, reducing seat wear and enhancing service life.

The full bore construction ensures minimal flow resistance, and the 3-piece design allows for easy maintenance and installation. The valve is equipped with a fire-resistant design in accordance with API6FA, ensuring safe operation even in hazardous environments. The valve operates with a worm gear for reliable and smooth control.

This valve is suitable for use in water, oil, and gas systems and operates effectively within a temperature range of -46°C to 100°C.

Specifications:

Features:

Fixed Ball Design: Reduces wear on the valve seat, increasing the service life of the valve.

Three-Piece Design: Allows for easy maintenance and is suitable for bi-directional flow systems, ensuring good sealing performance in both directions.

Full Bore Construction: Minimizes flow resistance for improved system efficiency.

Fire-Resistant Design: Complies with API6FA for safety in high-risk environments.

Worm Gear Operation: Provides smooth, reliable control of the valve.

If you require any further information on this listing please contact info@reflowx.com
