3 Way Ball Valve 8 Inch 150LB RF Forged Steel

Description

Product Description:

Overview:

This 3-Way Ball Valve is designed for multi-directional flow control in oil, water, and gas systems. The valve features a forged steel A105N body, offering strength and durability under high-pressure conditions. It operates with a bare stem, allowing for direct manual control and integration with actuators if needed.

The valve has a trunnion-mounted ball structure and is designed with RF (Raised Face) connection ends for secure and reliable sealing. The valve conforms to API 6D standards and operates within a temperature and pressure range defined by ASME B16.34.

Specifications:

Feature	Details
Type	Ball Valve
Size	8 Inch
Pressure Rating	150LB
Connection	RF (Raised Face Flange)
Operation	Bare Stem
Structure	Multi-Way, 3-Way, Trunnion-Mounted Ball
Body Material	ASTM A105N
Trim Material	SS316 + RPTFE
Design Code	API 6D
Pressure & Temp Code	ASME B16.34
Face to Face	ASME B16.10
End Connection	ASME B16.5
Inspection Code	API 598
Medium	Oil, Water, Gas

Features:

Forged Steel Construction: Made from A105N forged steel for strength and durability in high-pressure applications.

Trunnion-Mounted Ball: Ensures stable operation and minimal wear.

Multi-Way Design: Allows for flexible flow control, perfect for applications requiring redirection or distribution of flow.

Bare Stem Operation: Offers manual control, ideal for straightforward operation or actuator integration.

RF Connections: Raised Face Flange (RF) ensures secure and leak-proof installation.

High-Quality Trim Materials: SS316 + RPTFE trim materials ensure durability and corrosion resistance for reliable sealing.
