Product Description:

Overview:

This DN100 PN25 3-Way Floating Ball Valve is manufactured in accordance with ISO 17292 standards, offering a robust A351-CF8M body for superior corrosion resistance and durability. The valve has a T-shaped design and is equipped with a floating ball for efficient flow control.

The valve features bi-directional flow, ensuring reliable operation in both directions. It also boasts anti-fire, anti-static, and anti-flying valve stem properties for enhanced safety. The valve operates with a lever with dial, allowing for precise manual control in water, oil, and gas systems. It operates effectively within a temperature range of -29°C to 120°C.

Specifications:

Features:

Low Fluid Resistance: The T-shaped design and floating ball structure provide minimal fluid resistance and efficient flow control.

Simple Structure: The valve's compact size and lightweight construction make it easy to install and maintain.

Reliable Sealing: Offers tight and reliable sealing performance, even in harsh operating conditions.

Fire-Safe Design: Compliant with API 607 for fire-resistant operation in high-risk environments.

Bi-Directional Flow: Ensures reliable performance and sealing in both directions.

Convenient Operation: The lever with dial operation mode allows for smooth and precise valve control.

If you require any further information on this listing please contact info@reflowx.com
