Product Description:

Overview:

This DN80 PN16 Trunnion Mounted Ball Valve is manufactured according to API6D standards, with the body constructed from A105 for excellent strength and durability. The valve features a fixed ball, full bore design, and anti-fire, anti-static, and anti-flying valve stem properties, ensuring enhanced safety and reliable operation.

The valve's EN1092-1 B connection ensures a secure, leak-proof installation, while the gear operation (G.O) mode provides smooth and stable control. Designed to operate within a temperature range of -29°C to 121°C, this valve is ideal for use in water, oil, and gas systems under PN16 pressure.

Specifications:

Features:

Fixed Ball Design: Provides stable operation, minimizing wear and improving valve performance.

Anti-Fire and Anti-Static: Fire-resistant and anti-static features ensure safe operation in high-risk environments.

Anti-Flying Valve Stem: Prevents valve stem damage and enhances operational safety.

Full Bore Design: Ensures minimal flow restriction and optimal performance.

Gear Operation (G.O): Allows smooth, reliable valve control for efficient operation.

High Reliability: Simple structure with few components ensures low failure rate and long-term stable operation.

If you require any further information on this listing please contact info@reflowx.com
