Cast Steel Ball Valve | Flanged Ends | Class 150/300 | Lever Operated

ReflowX SKU: REF-1400

Product Details

Quantity

100
Availability (Lead Time)

6-10 Weeks
Product Location

United Arab Emirates
Condition

New
OEM

ReflowX
Equipment code

Get Quotation Whatsapp

Short Description

Robust cast steel ball valve with flanged ends and lever handle, available in ANSI Class 150 and Class 300 pressure ratings. Designed for on/off fluid control in industrial pipelines.

Description

Cast Steel Ball Valve | Flanged Ends | Class 150/300 | Lever Operated

Description:

This Cast Steel Ball Valve is a high-performance industrial valve designed for dependable shutoff in various fluid systems. Constructed from durable cast steel, it ensures strength and corrosion resistance under demanding operating conditions. The valve features a full or reduced bore stainless steel ball for tight sealing, a blowout-proof stem design, and an easy-to-operate lever handle. Its flanged ends allow secure integration into Class 150 or Class 300 ANSI pipelines. Suitable for water, oil, gas, and steam applications, this ball valve is engineered for long service life and minimal maintenance in petrochemical, power, and general industrial systems.

Specifications:

– Valve Type: 2-Way Ball Valve
– Body Material: Cast Steel (WCB/ASTM A216 or equivalent)
– Ball Material: Stainless Steel (SS304 or SS316, based on spec)
– Seat Material: PTFE, RPTFE, or other engineered polymers
– Size Range: 1/2” to 12” standard (larger sizes on request)
– Pressure Rating: ANSI Class 150 or Class 300
– End Connection: Flanged (ANSI B16.5)
– Operation: Manual Lever Handle
– Design Standard: API 608 / ASME B16.34
– Face-to-Face: ASME B16.10
– Leakage Class: API 598
– Working Temperature: -20°C to +200°C (depending on seat material)
– Working Pressure:
• Class 150: up to ~19 bar (285 psi)
• Class 300: up to ~49.6 bar (740 psi)
– Mounting: ISO 5211 pad optional for actuator installation
– Features: Blowout-proof stem, anti-static design, fire-safe optional
– Coating: Rust-protective primer or enamel (optional)
– Applications: Oil & gas, water treatment, power plants, chemical process

For further specifications or to inquire about this equipment and ReflowX's logistics services, Please contact ReflowX at info@reflowx.com

Technical Details

ISO 15926 Pt 4	10554
Height	150
Width	100
Weight	10 kg
ISO 15926 Pt 4	10554
PCA RDS Code	RDS292589
CFIHOS ID	CFIHOS-30000660
IFC Class	IfcValve
Failure Action	valve remains in last position
Fluid Name	Water,Oil and hydrocarbons,Air and gases,Chemicals
Full Opening Valve	Yes
Nominal Diameter	DN 15 (½”) to DN 300 (12”)
Normal Operating Pressure	Class 150: Up to 285 psi (19.6 bar) at 100°F (37.8°C)
Normal Operating Temperature	-29°C to +200°C
Piping Class	ANSI Class 150 and ANSI Class 300 flanged ends
UNSPSC Code	40141600
