LVF 3/4" Class 1500 Piston Check Valve – A105N, FNPT, Trim 8, NACE Compliant

The LVF 3/4" #1500 Piston Check Valve is a high-performance non-return valve designed for use in critical high-pressure systems. Engineered with a forged A105N carbon steel body and bolted cover, this valve is built to withstand demanding operating environments. It features FNPT threaded ends for easy integration into pipeline systems, and Trim 8 components for improved durability and corrosion resistance. The valve meets NACE MR0103 and MR0175 standards, making it suitable for sour gas and corrosive service conditions. Ideal for applications in the oil & gas, chemical, and refining industries.

Specifications:

– Valve Type: Piston Check Valve
– Size: 3/4 inch
– Pressure Rating: Class 1500
– Body Material: A105N Forged Carbon Steel
– End Connection: FNPT (Female NPT Threaded Ends)
– Bore Type: Reduced Bore (RB)
– Trim Type: Trim 8 (Standard corrosion-resistant alloy combination)
– Cover Type: Bolted Cover
– Design Feature: Piston-style internals for reliable backflow prevention
– Compliance: NACE MR0103 / MR0175
– Operation: Automatic, non-return (check) function
– Application Areas: Sour gas systems, upstream and downstream oilfield systems, petrochemical units, and high-pressure fluid lines

For further specifications or to inquire about this equipment and ReflowX's logistics services, Please contact ReflowX at info@reflowx.com
