Choke Valves – Swing & Non-Slam Type | Cast, Forged & Wafer Check Valves | ANSI 1500#

ReflowX SKU: REF-721

Product Details

Quantity

100
Availability (Lead Time)

4-6 Weeks
Product Location

United Arab Emirates
Condition

New
OEM

ReflowX
Equipment code

Get Quotation Whatsapp

Short Description

Robust choke valves including swing and non-slam types in cast steel, forged steel, and wafer design. Compliant with API 600, API 594, and ANSI standards up to 1500 lbs.

Description

Choke Valves - Swing & Non-Slam Type | Cast, Forged & Wafer Check Valves | ANSI 1500#
Description:

Our comprehensive range of choke valves includes swing and non-slam types manufactured from cast steel, forged steel, and wafer configurations to suit a variety of critical flow control applications. These check valves are engineered in compliance with leading international standards such as API 600, API 594, BS 1414, BS 1868, BS 5352, and API 602, offering reliability under high-pressure and high-temperature conditions. Available with raised face (RF), ring type joint (RTJ), threaded (NPT), and socket weld (SW) end connections, these valves serve well in oil & gas, petrochemical, power, and industrial process systems.

Specifications:

– Valve Types: Swing Type, Non-Slam Type Check Valves
– Body Materials: Cast Steel, Forged Steel
– Design Standards (Cast Steel):
• API 600, BS 1414, BS 1868, ANSI B16.34
• B1873 for globe/check valve integration
– Design Standards (Forged Steel):
• API 602, BS 5352
– Design Standards (Wafer Type):
• API 594 (Design), API 598 (Testing)
– Pressure Ratings: ANSI Class 150 to 1500 lbs
– Available Sizes:
• Cast Steel: 2" – 56"
• Forged Steel: 1/2" – 2"
• Wafer Type: 2" – 24"
– Connection Types: RF, RTJ, NPT, SW
– Valve Function: Prevent reverse flow (unidirectional), protect pumps and compressors
– Body Coating: Anti-corrosive industrial coating (color varies per spec)
– Application Areas: Oil & Gas, Refineries, Power Plants, Petrochemicals, Offshore Platforms
– Testing Compliance: API 598 (Hydrostatic & Seat Testing)

For further specifications or to inquire about this equipment and ReflowX's logistics services, Please contact ReflowX at info@reflowx.com

Technical Details

ISO 15926 Pt 4	10554
Height	150–200 mm
Width	100 mm to 450 mm
Length	292 mm - 559 mm
Weight	15 - 250 kg
ISO 15926 Pt 4	10554
PCA RDS Code	RDS292589
CFIHOS ID	CFIHOS-30000660
IFC Class	IfcValve
Design Specification	Swing Check, Non-Slam Check
Failure Action	Closes automatically upon flow reversal
Fluid Name	Hydrocarbon liquids, Natural gas, Steam, Water, Process chemicals
Full Opening Valve	Yes
Nominal Diameter	½" to 2"
Normal Operating Pressure	3,705 PSI
Normal Operating Temperature	-29°C to +425°C
Piping Class	ASME B31.3
UNSPSC Code	40141600
