Douglas Chero Forged Steam Traps – ½” to 1”

ReflowX SKU: REF-2132

Product Details

Quantity

50
Availability (Lead Time)

0-2 Weeks
Product Location

United Arab Emirates
Condition

New
OEM

Douglas Chero, Italy
Equipment code

Get Quotation Whatsapp

Short Description

Douglas Chero forged steam traps, ½” to 1”, Class 600, available in forged A105N, F316L, LF2, or F22 bodies with RD or FB bore and RF, NPT, or SW end connections.

Description

Douglas Chero Forged Steam Traps – ½” to 1”, Class 600, A105N/F316L/LF2/F22

Douglas Chero forged steam traps are designed for efficient removal of condensate and non-condensable gases from steam systems without loss of live steam. These compact, high-performance units are manufactured in Italy and offered in ½” to 1” sizes with Class 600 pressure ratings. Built from durable forged materials such as A105N carbon steel, F316L stainless steel, LF2 for low-temperature service, and F22 alloy steel, these steam traps are well-suited for high-pressure and high-temperature applications. Available with Raised Face (RF), Threaded (NPT), or Socket Weld (SW) end connections and Reduced Bore (RD) or Full Bore (FB) configurations, they ensure tight sealing, resistance to corrosion, and long service life. Suitable for use in refineries, petrochemical plants, and steam distribution systems, Douglas Chero steam traps help improve energy efficiency and maintain process performance.

Specifications:

– Manufacturer: Douglas Chero, Italy
– Product Type: Forged Steam Trap
– Size Range: ½” to 1”
– Pressure Class: Class 600
– Body Materials:
• A105N – Carbon Steel
• F316L – Stainless Steel
• LF2 – Low-Temperature Carbon Steel
• F22 – Chrome-Moly Alloy Steel
– End Connections:
• RF – Raised Face Flanged
• NPT – Threaded (ASME B1.20.1)
• SW – Socket Weld (ASME B16.11)
– Bore Options:
• Reduced Bore (RD)
• Full Bore (FB)
– Design Features:
• Forged one-piece body
• High-resistance seat and internals
• Thermodynamic or mechanical design (dependent on model)
• Corrosion-resistant construction
• Optimized for condensate discharge without live steam loss
– Standards & Testing:
• ASME B16.34
• MSS SP-25 (Marking)
• API 598 (Pressure Testing)
– Applications:
• Steam Distribution Networks
• Petrochemical Processing
• Chemical Plants
• Refining & Oil Facilities
• Power Generation

For further specifications or to inquire about this equipment and ReflowX's logistics services, Please contact ReflowX at info@reflowx.com

Technical Details

ISO 15926 Pt 4	10554
Model Number	Forged Steam Trap
Manufacturer Name	Douglas Chero, Italy
Height	90 mm to 165 mm
Width	65 mm to 110 mm
Length	80 mm to 150 mm
Weight	1.8 kg (½” NPT) to 7.5 kg
ISO 15926 Pt 4	10554
PCA RDS Code	RDS292589
CFIHOS ID	CFIHOS-30000660
IFC Class	IfcValve
Design Specification	ASME B16.34 – Valve Design Standard
Failure Action	Closed on failure (non-opening under failed pressure differential)
Fluid Name	Steam ,Condensate, Non-condensable gases
Full Opening Valve	No
Nominal Diameter	½” (DN15), ¾” (DN20), 1” (DN25)
Normal Operating Pressure	Up to 99 bar
Normal Operating Temperature	-29°C to +425°C
Piping Class	ASME B1.20.1
UNSPSC Code	40141600
