NSW Electric Actuator Ball Valve – Motorized Control, Floating & Trunnion Designs

The NSW Electric Actuator Ball Valve is a precision-controlled motorized valve designed for use in industrial automation systems. It features electric actuation for remote or automated flow regulation and is available in floating, fixed (trunnion-mounted), and elastic ball configurations depending on the pressure, temperature, and application needs.

Floating ball valves offer a simple design with reliable sealing for medium and low-pressure systems, where the ball is allowed to move slightly to press against the downstream seat. Trunnion (fixed ball) valves, on the other hand, are ideal for high-pressure or large-diameter pipelines, incorporating bearing-supported shafts and independently floating seats that enhance sealing and reduce operating torque. For severe conditions, elastic ball designs allow additional compression by the valve stem wedge to ensure metal-to-metal sealing.

This electric actuator ball valve is suitable for cutting off or regulating flow in chemical, power, petrochemical, water treatment, and other industrial sectors. Available with flange, thread, or butt-weld end connections and in various actuator options—electric, pneumatic-electric, or electro-hydraulic—it ensures dependable automated control and sealing performance across a wide range of pressures and temperatures.

Specifications:

– Valve Type: Electric actuator-operated ball valve
– Operation: Electric motorized (on/off or modulating control)
– Ball Type: Floating, Fixed (Trunnion), Elastic
– Seat Material: Metal or Soft Seat (PTFE, RPTFE, etc.)
– Size Range: NPS ½″ to 48″ (depending on configuration)
– Pressure Class: 150 to 2500
– Temperature Range: Up to 425°C (elastic ball), –40°C to –196°C (cryogenic available)
– Body Materials:
 • Forged: A105, A182 F304/F316, F51, F53, LF2
 • Cast: A216 WCB, A351 CF8/CF8M/CF3/CF3M, A352 LCB, LCC
 • Alloys: Monel, Inconel, Hastelloy, UB6
– End Connections:
 • Flanged (RF, FF, RTJ) per ASME B16.5/B16.47
 • Socket Weld (ASME B16.11)
 • Butt Weld (ASME B16.25)
 • Threaded (ASME B1.20.1)
 • Wafer/Lug (for compact designs)
– Actuator Options: Electric, Electro-hydraulic, Pneumatic-electric
– Body Design: One-piece, Two-piece, Three-piece, Side or Top Entry
– Design Standards: API 6D, API 608, ISO 17292, ASME B16.34
– Face-to-Face: ASME B16.10
– Testing & Inspection: API 598, API 6D, ISO 15848, NACE MR-0175/MR-0103

For further specifications or to inquire about this equipment and ReflowX's logistics services, Please contact ReflowX at info@reflowx.com
