FBV Forged Ball Valves – ½” to 2”

ReflowX SKU: REF-8423

Product Details

Quantity

50
Availability (Lead Time)

0-2 Weeks
Product Location

United Arab Emirates
Condition

New
OEM

FBV Inc., USA
Equipment code

Get Quotation Whatsapp

Short Description

High-performance FBV forged steel ball valves, made in the USA, available in sizes ½” to 2” with pressure ratings from Class 150 to Class 1500. Ideal for high-pressure industrial flow control.

Description

FBV Forged Ball Valves – ½” to 2”, Class 150 to 1500, USA

FBV ball valves are engineered in the USA for demanding flow isolation applications across oil & gas, petrochemical, and industrial sectors. These forged steel valves are available in sizes ranging from ½” to 2” and pressure classes 150, 300, 600, 800, and 1500. The compact yet robust design ensures high cycle life and leak-tight performance under extreme pressures and temperatures. The valves are typically available in full or reduced bore, with options for NPT, SW, and RF connections. Their quarter-turn operation and blowout-proof stem design make them reliable and safe for critical applications. FBV’s commitment to API standards, precision machining, and material integrity make these ball valves a preferred choice for industrial projects worldwide.

Specifications:

– Manufacturer: FBV Inc., USA
– Product Type: Forged Steel Ball Valve
– Size Range: ½” to 2”
– Pressure Ratings:
• Class 150
• Class 300
• Class 600
• Class 800
• Class 1500
– Body Material: Forged Carbon Steel (A105), Stainless Steel (F316/F316L), LF2 (optional)
– End Connections:
• NPT – Threaded
• SW – Socket Weld
• RF – Raised Face Flanged
– Bore Options:
• Full Bore
• Reduced Bore
– Operation:
• Quarter-turn with lever or gear operator
• Blowout-proof stem design
• Lockable handle (optional)
– Seat & Sealing Options:
• PTFE, RPTFE, or Metal Seats (optional)
– Design Features:
• Anti-static device
• Fire-safe design (per API 607)
• ISO 5211 mounting pad for actuators (optional)
• Low emission packing available
– Compliance & Testing:
• API 598 (pressure testing)
• ASME B16.34
• Fire Safe – API 607
• NACE MR0175 (optional)
For further specifications or to inquire about this equipment and ReflowX's logistics services, Please contact ReflowX at info@reflowx.com

Technical Details

Year of Manufacturing	FBV Inc., USA
ISO 15926 Pt 4	10554
Model Number	Forged Steel Ball Valve
Year of Manufacturing	FBV Inc., USA
Height	70 mm to 170 mm
Width	50 mm to 100 mm
Length	108 mm to 216 mm
Weight	1.5 kg to 11 kg
ISO 15926 Pt 4	10554
PCA RDS Code	RDS292589
CFIHOS ID	CFIHOS-30000660
IFC Class	IfcValve
Design Specification	Forged Steel Ball Valve
Failure Action	Manual valves remain in position unless actuated
Fluid Name	Crude oil, refined fuels, natural gas, steam, Water, brine, hydraulic oil, air
Full Opening Valve	Yes – available in Full Bore and Reduced Bore
Nominal Diameter	½”, ¾”, 1”, 1½”, 2”
Normal Operating Pressure	19 bar to 257 bar
Normal Operating Temperature	-29°C to +200°C
Piping Class	Classes 150 / 300 / 600 / 800 / 1500
UNSPSC Code	40141600
