Gate Valve – 400 mm (DN 400), WCB, Class 150, Flanged Ends

ReflowX SKU: REF-1065

Product Details

Quantity

1
Availability (Lead Time)

0-2 Weeks
Product Location

United Arab Emirates
Condition

New
OEM

ReflowX
Equipment code

Get Quotation Whatsapp

Short Description

Heavy-duty 400 mm (DN 400) cast carbon steel gate valve with Class 150 rating and bolted bonnet, designed for full-bore flow in industrial pipelines. API 600 compliant.

Description

Gate Valve – 400 mm (DN 400), WCB, Class 150, Flanged Ends

This 400 mm (DN 400) Gate Valve is a robust, full-bore shutoff valve constructed from WCB (ASTM A216 Cast Carbon Steel) for reliable performance in demanding industrial environments. Designed in accordance with API 600 / API 602, this valve features a bolted bonnet, solid wedge disc, and stainless steel trim, making it suitable for a wide range of process media, including water, steam, and non-corrosive fluids.

The valve offers a Class 150 pressure rating (PN 20) and supports a maximum working pressure of 20 bar (290 PSI). It is equipped with raised face (RF), flat face (FF), or RTJ flanges, compliant with ASME B16.5, and features a two-piece gland design with graphite or PTFE-based packing, ensuring reliable high-temperature sealing up to 425°C (797°F).

The full-bore linear flow path minimizes pressure drop, making this gate valve ideal for systems requiring unrestricted flow. It is pressure-tested in accordance with API 598 and meets fire safety standards API 607. The valve’s face-to-face dimensions conform to ASME B16.10, and all valve markings are per MSS SP-25.

Specifications:

– Type: Gate Valve
– Size: 400 mm (DN 400)
– Pressure Class: Class 150 (PN 20)
– Material (Body): ASTM A216 WCB (Cast Carbon Steel)
– Bonnet Type: Bolted Bonnet
– Disc Type: Solid Wedge
– Stem Material: Stainless Steel (AISI 410 or equivalent)
– Seat Ring Material: Stainless Steel / Renewable
– Packing Material: Graphite or PTFE-based
– Gland Type: Two-piece gland with bolted design
– Maximum Working Pressure: 20 bar (290 PSI)
– Maximum Operating Temperature: 425°C (797°F)
– Flow Characteristic: Linear, Full Bore
– Flange Standard: ASME B16.5
– Face Type: RF / FF / RTJ (as required)
– Bolt Holes: Per ASME B16.5 Class 150
– Shell Test Pressure: 30 bar (1.5 × rated pressure)
– Seat Test Pressure: 22 bar (1.1 × rated pressure)
– Design Standard: API 600 / API 602
– Testing Standard: API 598
– Face-to-Face Standard: ASME B16.10
– Fire Safety Compliance: API 607
– Marking Standard: MSS SP-25
– Markings on Valve: 400X19
For further specifications or to inquire about this equipment and ReflowX's logistics services, Please contact ReflowX at info@reflowx.com

Technical Details

ISO 15926 Pt 4	10554
Height	550 mm
Width	250 mm
Length	230 mm
Weight	36 kg
ISO 15926 Pt 4	10554
PCA RDS Code	RDS292589
CFIHOS ID	CFIHOS-30000660
IFC Class	IfcValve
Design Specification	API 600 / ASME B16.34
Failure Action	Fail Closed
Fluid Name	Water, Oil, Gas, Steam
Full Opening Valve	Yes
Nominal Diameter	DN100 (4 inches)
Normal Operating Pressure	150 psi
Normal Operating Temperature	-10°C to +200°C
Piping Class	ANSI B16.5 Class 150 / 300 / 600 / 900 / 1500 / 2500
UNSPSC Code	40141600
