Gate Valves | Cast & Forged Steel | ANSI Class up to 1500 lbs | RF, RTJ, NPT, SW Connections

ReflowX SKU: REF-7607

Product Details

Quantity

100
Availability (Lead Time)

4-6 Weeks
Product Location

United Arab Emirates
Condition

New
OEM

ReflowX
Equipment code

Get Quotation Whatsapp

Short Description

Durable Cast and Forged Steel Gate Valves available in sizes ranging from 1/2" to 48", engineered to meet API and BS standards. Designed for ANSI pressure classes up to 1500 lbs with multiple connection types including RF, RTJ, NPT, and SW, ideal for reliable isolation in oilfield and industrial applications.

Description

Gate Valves | Cast & Forged Steel | ANSI Class up to 1500 lbs | RF, RTJ, NPT, SW Connections
Description:

Our comprehensive range of Gate Valves includes both Cast Steel and Forged Steel designs engineered for robust and reliable flow isolation in critical industrial and oilfield environments. The Cast Steel Gate Valves comply with API 600, BS1414, B1873, and BS1868 standards and are available in sizes from 2" to 48". These valves support ANSI pressure classes up to 1500 lbs and come with Raised Face (RF) and Ring Type Joint (RTJ) flange connections.

Forged Steel Gate Valves are manufactured according to API 602 and BS5352 standards, covering sizes from 1/2" to 2" and rated for ANSI class pressures up to 1500 lbs. Their connection options include RF, RTJ, NPT (threaded), and SW (socket weld), providing flexibility for various piping systems and installation requirements.

Both valve types are built for heavy-duty applications, offering tight shutoff, high pressure handling capability, and long-term durability. Ideal for oil & gas, petrochemical, power generation, and other demanding industrial sectors.

Specification:

– Model: Cast & Forged Steel Gate Valve
– Size Range Cast Steel: 2" – 48"
– Size Range Forged Steel: 1/2" – 2"
– Working Pressure (WP): ANSI Class up to 1500 lbs
– Connection Types: Raised Face (RF), Ring Type Joint (RTJ), Threaded (NPT), Socket Weld (SW)
– Body Material: Cast Steel (API 600, BS1414, B1873, BS1868), Forged Steel (API 602, BS5352)
– Design Standard: API 600, API 602, BS1414, BS1868, BS5352
– Valve Type: Gate Valve, Manual Operation (Gear or Handwheel)
– Face-to-Face Dimensions: Per API 6D or applicable standard
– End Connections: RF, RTJ, NPT, SW as specified
– Temperature Range: Typically -29°C to +121°C (subject to material and design)
– Operation: Manual (gear or handwheel)
– Seal Type: Metal-to-metal or elastomeric (configurable)
– Application: Oilfield isolation, pipeline shutoff, industrial flow control
– Color: Manufacturer standard (typically industrial grey or black)
– Country of Origin: [To be specified]
– Compliance: Meets API and BS material, pressure, and design standards
For further specifications or to inquire about this equipment and ReflowX's logistics services, Please contact ReflowX at info@reflowx.com

Technical Details

ISO 15926 Pt 4	10554
Model Number	Cast & Forged Steel Gate Valve
Height	350 mm to 2,200 mm
Width	600 mm
Length	178 mm to 1,900 mm
Weight	4 kg to 1,200+ kg
ISO 15926 Pt 4	10554
PCA RDS Code	RDS292589
CFIHOS ID	CFIHOS-30000660
IFC Class	IfcValve
Design Specification	Gate Valve
Failure Action	fails in last position
Fluid Name	Crude oil, Natural gas, Steam, Water, Chemical service fluids
Full Opening Valve	Yes
Nominal Diameter	2" to 48"
Normal Operating Pressure	3,705 PSI @ 100°F
Normal Operating Temperature	-29°C to +425°C
Piping Class	classes 150 to 1500
UNSPSC Code	40141600
