Globe Valves | Cast & Forged Steel | RF, RTJ, NPT & SW Connections| ANSI Class up to 1500 lbs

ReflowX SKU: REF-7876

Product Details

Quantity

100
Availability (Lead Time)

4-6 Weeks
Product Location

United Arab Emirates
Condition

New
OEM

ReflowX
Equipment code

Get Quotation Whatsapp

Short Description

High-performance Cast and Forged Steel Globe Valves available in sizes from 1/2" to 48", designed for ANSI Class ratings up to 1500 lbs. Offered with RF, RTJ, NPT, and SW connections and compliant with API and BS standards for precise throttling and flow regulation in industrial and oilfield systems.

Description

Globe Valves | Cast & Forged Steel | RF, RTJ, NPT & SW Connections| ANSI Class up to 1500 lbs
Description

Our Cast and Forged Steel Globe Valves are engineered for high-integrity flow regulation and throttling in demanding industrial environments. Designed in accordance with globally recognized standards such as API 600, API 602, BS1414, B1873, BS1868, and BS5352, these valves ensure optimal performance in a wide range of pressure and temperature conditions.

Cast Steel Globe Valves are offered in sizes from 2" to 48" and support ANSI Class ratings up to 1500 lbs, with connection options including Raised Face (RF) and Ring Type Joint (RTJ) flanges. These valves are ideal for medium to large-scale process systems requiring durable and reliable shutoff or flow control.

Forged Steel Globe Valves, built to API 602 and BS5352 standards, cover smaller sizes from 1/2" to 2" and are also rated for ANSI Class up to 1500 lbs. Available connection types include RF, RTJ, NPT (threaded), and SW (socket weld), making them highly adaptable for tight installations and high-pressure service lines.

These valves offer excellent shutoff capabilities and are typically used in industries such as oil & gas, power generation, petrochemicals, and water treatment.

Specification:

– Model: Cast & Forged Steel Globe Valve
– Size Range (Cast Steel): 2" – 48"
– Size Range (Forged Steel): 1/2" – 2"
– ANSI Pressure Class Rating: Up to 1500 lbs
– Connection Types: Raised Face (RF), Ring Type Joint (RTJ), Threaded (NPT), Socket Weld (SW)
– Body Material: Cast Steel (API 600, BS1414, B1873, BS1868), Forged Steel (API 602, BS5352)
– Design Standards: API 600, API 602, BS1414, BS1868, BS5352
– Valve Type: Globe Valve – Angle or Straight Pattern (as applicable)
– Bonnet Type: Bolted or Pressure Seal (based on pressure rating)
– Disc Type: Plug, Ball, or Needle Type (to be specified)
– Seat Type: Integral or Renewable
– Operation: Manual (Handwheel or Gear Operated); Automation available on request
– Face-to-Face Dimensions: As per ASME B16.10
– Temperature Range: Typically -29°C to +425°C (subject to trim and seat material)
– Testing Standard: API 598
– Application: Flow throttling and regulation in oil & gas, refining, chemical, and industrial sectors
– Color: Manufacturer standard (typically industrial grey or black)
– Country of Origin: [To be specified]
– Compliance: Fully compliant with API and BS design and testing standards
For further specifications or to inquire about this equipment and ReflowX's logistics services, Please contact ReflowX at info@reflowx.com

Technical Details

Height	120 mm to 300 mm
Width	120 mm
Length	80 mm to 180 mm
Weight	90 kg
Design Specification	Gate Valve
Failure Action	fails in last position
Fluid Name	Crude oil, Natural gas, Steam, Water, Chemical service fluids
Full Opening Valve	Yes
Nominal Diameter	1/2" to 2"
Normal Operating Pressure	~285 PSI @ 100°F
Normal Operating Temperature	-29°C to +425°C
Piping Class	ANSI/ASME B31.3

General Terms

ReflowX and the seller retain the right to evaluate and approve offers.
Buyers should verify quantities and conditions upon delivery.
After successful engagement, both buyer and seller manage communication for payment terms and delivery schedule.
All parties agree to adhere to ReflowX Terms and Conditions in transactions.
Buyers can request value-added services such as pre-purchase inspections, Expediting & Delivery Services through ReflowX. Contact us!
