Globe Valves – ½” to 12”, ANSI/DIN/JIS, Cast & Forged Materials, Flanged or Threaded Ends

ReflowX SKU: REF-6767

Product Details

Quantity

300
Availability (Lead Time)

6-10 Weeks
Product Location

United Arab Emirates
Condition

New
OEM

USA, Singapore, India, China, Korea
Equipment code

Get Quotation Whatsapp

Short Description

High-performance globe valves from ½” to 12” for throttling applications, available in a range of cast and forged metals, with flanged, socket weld, and NPT threaded ends to ANSI, DIN, and JIS standards.

Description

Globe Valves – ½” to 12”, ANSI/DIN/JIS, Cast & Forged Materials, Flanged or Threaded Ends

These industrial-grade globe valves are engineered for precise flow regulation in demanding service environments. Offered in sizes from ½” to 12”, they are manufactured using robust materials including cast iron, cast steel, forged steel, stainless steel, and brass/bronze. Designed to conform to ANSI, DIN, and JIS standards, these valves are suitable for working pressures up to 1000 PSI. Available end connections include NPT threaded, socket weld, and flanged to match system requirements. Featuring a disc-and-seat mechanism, these globe valves provide superior throttling performance with minimal leakage. Their durable construction and wide material compatibility make them suitable for oil & gas, HVAC, water treatment, steam systems, and marine applications. Manufactured in the USA, Singapore, India, China, and Korea, these valves ensure international reliability and compliance.

Specification:

– Product Type: Globe Valve
– Material Options:
– Cast Iron
– Cast Steel
– Forged Steel
– Brass/Bronze
– Stainless Steel
– Size Range: ½” to 12”
– Pressure Ratings:
– PN Ratings: PN10, PN16
– JIS Ratings: 5K, 10K
– ANSI Ratings: CL150, CL200, CL900
– Others: Up to 1000 PSI
– Standards: JIS, DIN, ANSI
– End Connections:
– NPT Threaded
– Socket Weld
– Flanged (ANSI/JIS/DIN)
– Design: Globe-type seat with plug or disc closure
– Face Type: Raised Face or Flat Face
– Surface Finish:
– Cast Iron & Steel: Painted or epoxy coated
– Stainless Steel: Polished or passivated
– Origin: USA, Singapore, India, China, Korea

For further specifications or to inquire about this equipment and ReflowX's logistics services, Please contact ReflowX at info@reflowx.com

Technical Details

ISO 15926 Pt 4	10554
Height	100 mm - 700 mm
Width	60 mm - 400 mm
Length	140 mm - 500 mm
Weight	4 kg -120 kg
ISO 15926 Pt 4	10554
PCA RDS Code	RDS292589
CFIHOS ID	CFIHOS-30000660
IFC Class	IfcValve
Failure Action	Manual fail-state control
Fluid Name	Water, Steam, Air, Non-corrosive Chemicals, Fuel, Process Fluids
Full Opening Valve	No
Nominal Diameter	Range: ½” to 12”
Normal Operating Pressure	1000 PSI
Normal Operating Temperature	−10°C to +425°C
Piping Class	Class 150–600
UNSPSC Code	40141600
