GWC Italy Ball Valves – ½” to 24”, 150# to 6000#, RF/RTJ/SW/NPT Ends

ReflowX SKU: REF-1574

Product Details

Quantity

50
Availability (Lead Time)

0-2 Weeks
Product Location

United Arab Emirates
Condition

New
OEM

GWC VALVES ITALY
Equipment code

Get Quotation Whatsapp

Short Description

GWC Valves Italy ball valves in sizes ½” to 24” with pressure classes ranging from 150# to 6000#, available in WCB, A105N, F316L, and LF2 bodies with RF, RTJ, NPT, SW, and LRF ends for robust industrial applications.

Description

GWC Italy Ball Valves – ½” to 24”, 150# to 6000#, RF/RTJ/SW/NPT Ends
Description:

GWC Valves Italy offers a comprehensive range of high-performance ball valves engineered for demanding industrial environments, including oil & gas, petrochemical, power, and marine sectors. Available in sizes from ½” to 24”, these valves are built to handle pressure ratings from 150# up to 6000#. GWC ball valves are manufactured using high-quality materials such as WCB, A105N, F316L, LCC, and LF2 to ensure exceptional strength and corrosion resistance. Customers can choose between reduced bore (RD) and full bore (FB) configurations, with end connections including RF (Raised Face), RTJ (Ring Type Joint), LRF (Large Raised Face), NPT (National Pipe Thread), and SW (Socket Weld). GWC’s engineering excellence ensures superior performance in isolation and control applications across a broad range of process systems.

Specifications:

– Manufacturer: GWC ITALIA, Inc.
– Valve Type: Ball Valve
– Size Range: ½” to 24”
– Pressure Ratings: 150#, 300#, 600#, 800#, 900#, 1500#, 2500#, 6000#
– Body Materials:
– WCB
– A105N
– F316L
– LCC
– LF2
– End Connections:
–RF (Raised Face)
– RTJ (Ring Type Joint)
– LRF (Large Raised Face)
– NPT (Threaded)
– SW (Socket Weld)
– Bore Options:
– Reduced Bore (RD)
– Full Bore (FB)
– Standards: API, ASME, ANSI
– Applications:
– Oil & Gas
– Petrochemical
– Chemical
– Mining & Minerals
– Power Generation
– Marine
– Industrial Processing
For further specifications or to inquire about this equipment and ReflowX's logistics services, Please contact ReflowX at info@reflowx.com

Technical Details

ISO 15926 Pt 4	10554
Model Number	Ball Valve
Manufacturer Name	GWC ITALIA, Inc.
Height	150 mm for ½” to over 1200 mm for 24”
Width	100 mm to 900+ mm
Length	140 mm for 2" Class 150 to ~1600 mm for 24" Class 600
Weight	5 kg (½” 150#) to 2,500+ kg
ISO 15926 Pt 4	10554
PCA RDS Code	RDS292589
CFIHOS ID	CFIHOS-30000660
IFC Class	IfcValve
Design Specification	API 6D / API 608
Failure Action	fail-closed or fail-open
Fluid Name	Suitable for Oil, Gas, Steam, Water, Chemicals, and Slurries
Full Opening Valve	Full Bore (FB) and Reduced Bore (RD)
Nominal Diameter	½” to 24” (DN15 to DN600)
Normal Operating Pressure	150 psi to 6000 psi
Normal Operating Temperature	-46°C to +200°C
Piping Class	Compatible with ASME/ANSI Class 150, 300, 600, 800, 900, 1500, 2500, 6000 systems
UNSPSC Code	40141600
