MT Group 2" Floating Lever Operated Ball Valve – Class 600, WCB Body, F316 Ball, PTFE Seat

The MT Group 2" Class 600 Floating Lever Operated Ball Valve is designed for reliable operation in high-pressure piping systems. Featuring a robust split-body construction made from ASTM A216 WCB carbon steel, this valve ensures durability in demanding industrial environments. Internally, the valve is equipped with a precision-machined A182 F316 stainless steel ball and stem for enhanced corrosion resistance and longevity. The PTFE soft seats offer excellent sealing capability, while the raised face (RF) flanged ends ensure compatibility with standard ASME piping connections. This valve is ideally suited for applications in chemical processing, petrochemical plants, and oil & gas systems.

Specifications:

– Valve Type: Floating Ball Valve
– Operation: Manual Lever Operated
– Size: 2 inch
– Pressure Class: 600#
– Body Type: Split Body
– Body Material: ASTM A216 WCB (Carbon Steel)
– Ball Material: ASTM A182 F316 (Stainless Steel)
– Stem Material: ASTM A182 F316
– Seat Material: PTFE (Polytetrafluoroethylene)
– End Connection: Raised Face (RF) Flanged
– Design Standard: API 608 / ASME B16.34 (typical)
– Face-to-Face Standard: ASME B16.10
– Flange Standard: ASME B16.5
– Application: Suitable for oil, gas, steam, water, and chemical systems
– Temperature & Pressure Rating: As per ASME B16.34 limits for Class 600

For further specifications or to inquire about this equipment and ReflowX's logistics services, Please contact ReflowX at info@reflowx.com
