MT Group 3" Floating Lever Operated Ball Valve – Class 300, WCB Body, F316 Ball, PTFE Seat

The MT Group 3" Floating Lever Operated Ball Valve is engineered for reliable shut-off performance in high-pressure environments. Designed to ASME Class 300 specifications, the valve features a durable split-body design constructed from A216 WCB carbon steel. Its internal components, including the precision-machined ball and stem, are made from corrosion-resistant A182 F316 stainless steel, while PTFE seats ensure leak-proof sealing across a wide temperature range. The raised face (RF) flanged ends offer compatibility with standard piping systems, making it suitable for chemical, oil & gas, and industrial process applications.

Specifications:

– Valve Type: Floating Ball Valve
– Operation: Manual Lever Operated
– Size: 3 inch
– Pressure Class: 300#
– Body Construction: Split Body
– Body Material: ASTM A216 WCB (Carbon Steel)
– Ball Material: ASTM A182 F316 (Stainless Steel)
– Stem Material: ASTM A182 F316
– Seat Material: PTFE (Polytetrafluoroethylene)
– End Connection: Raised Face (RF) Flanged
– Design Standard: API 608 / ASME B16.34 (typical)
– Face-to-Face Standard: ASME B16.10
– Flange Standard: ASME B16.5
– Application: Industrial shut-off for water, oil, gas, and chemicals
– Temperature & Pressure Rating: As per ASME B16.34 limits for Class 300

For further specifications or to inquire about this equipment and ReflowX's logistics services, Please contact ReflowX at info@reflowx.com
