MT Group 3" Floating Lever Operated Ball Valve – Class 600, WCB Body, F316 Ball, PTFE Seat

The MT Group 3" Class 600 Floating Lever Operated Ball Valve is engineered for high-pressure flow control in demanding environments. Designed with a robust split-body made of ASTM A216 WCB carbon steel, this valve offers excellent mechanical strength and corrosion resistance. The internal components, including the precision-machined ball and stem, are manufactured from A182 F316 stainless steel to ensure superior performance in corrosive service conditions. The valve uses PTFE seating to provide reliable tight shutoff. Raised Face (RF) flanged ends conform to standard piping systems, making it suitable for oil & gas, chemical, steam, and water applications.

Specifications:

– Valve Type: Floating Ball Valve
– Operation: Manual Lever Operated
– Size: 3 inch
– Pressure Class: 600#
– Body Type: Split Body
– Body Material: ASTM A216 WCB (Carbon Steel)
– Ball Material: ASTM A182 F316 (Stainless Steel)
– Stem Material: ASTM A182 F316
– Seat Material: PTFE (Polytetrafluoroethylene)
– End Connection: Raised Face (RF) Flanged
– Design Standard: API 608 / ASME B16.34 (typical)
– Face-to-Face Standard: ASME B16.10
– Flange Standard: ASME B16.5
– Application: Oil & gas, petrochemical, steam, water systems
– Temperature & Pressure Rating: As per ASME B16.34 for Class 600 valves

For further specifications or to inquire about this equipment and ReflowX's logistics services, Please contact ReflowX at info@reflowx.com
