MT Group 4" Floating Lever Operated Ball Valve – Class 600, WCB Body, F316 Ball, PTFE Seat

The MT Group 4" Class 600 Floating Lever Operated Ball Valve is designed for demanding industrial applications requiring high pressure containment and reliable shutoff. Featuring a split-body configuration crafted from ASTM A216 WCB carbon steel, this valve ensures durability and resistance to mechanical stress. The internal components are made from ASTM A182 F316 stainless steel, offering excellent corrosion resistance and long service life in aggressive environments. The PTFE seat ensures bubble-tight sealing and reduced wear. Raised Face (RF) flanged ends conform to standard pipeline systems, making this valve suitable for use in oil & gas, chemical processing, steam, and general utility lines.

Specifications:

– Valve Type: Floating Ball Valve
– Operation: Manual Lever Operated
– Size: 4 inch
– Pressure Class: 600#
– Body Type: Split Body
– Body Material: ASTM A216 WCB (Carbon Steel)
– Ball Material: ASTM A182 F316 (Stainless Steel)
– Stem Material: ASTM A182 F316
– Seat Material: PTFE (Polytetrafluoroethylene)
– End Connection: Raised Face (RF) Flanged
– Design Standard: API 608 / ASME B16.34 (typical)
– Face-to-Face Standard: ASME B16.10
– Flange Standard: ASME B16.5
– Application: Oil & gas, petrochemical, steam, water distribution
– Temperature & Pressure Rating: As per ASME B16.34 for Class 600

For further specifications or to inquire about this equipment and ReflowX's logistics services, Please contact ReflowX at info@reflowx.com
