MT Group 8" Floating Lever Operated Ball Valve – Class 150, WCB Body, F316 Ball, PTFE Seat

The MT Group 8" Floating Lever Operated Ball Valve is a robust industrial solution designed for general-purpose flow control in pipelines. Built with a split body of A216 WCB carbon steel, this Class 150 valve features a corrosion-resistant A182 F316 stainless steel ball and stem for improved reliability and extended service life. The valve incorporates PTFE seats for chemical resistance and tight sealing performance. Raised face (RF) flanges ensure a strong pressure-tight connection, and the lever-operated design allows easy manual actuation. Ideal for oil & gas, petrochemical, and utility applications where durable construction and ease of maintenance are required.

Specifications:

– Valve Type: Floating Ball Valve
– Operation: Lever Operated
– Size: 8 inch
– Pressure Class: 150#
– Body Type: Split Body
– Body Material: ASTM A216 WCB (Carbon Steel)
– Ball Material: ASTM A182 F316 (Stainless Steel)
– Seat Material: PTFE (Polytetrafluoroethylene)
– Stem Material: ASTM A182 F316
– End Connection: Raised Face (RF) Flanged
– Design Standard: API 608 / ASME B16.34 (typical)
– Face-to-Face Dimension Standard: ASME B16.10
– Flange Standard: ASME B16.5
– Applications: General service, water, oil, gas, chemicals
– Temperature & Pressure Rating: As per ASME B16.34 limits for Class 150

For further specifications or to inquire about this equipment and ReflowX's logistics services, Please contact ReflowX at info@reflowx.com
