MT Group Gate Valve – 10" Class 150 RF, Bolted Bonnet, WCB Body, A182 F6a Stem

Product Details

Quantity

3
Availability (Lead Time)

0-2 Weeks
Product Location

United Arab Emirates
Condition
OEM

MT GROUP
Equipment code

CFIHOS-30000649
Total Price
Per Unit Price

$ 905.00

Short Description

10" Class 150 gate valve from MT Group with raised face flanges, WCB body, 13Cr hard-faced disc, A105N+STL.6 seat, A182 F6a stem, and bolted bonnet with flexible wedge.

Description

MT Group Gate Valve – 10" Class 150 RF, Bolted Bonnet, WCB Body, A182 F6a Stem

The MT Group 10-inch Class 150 gate valve is built to deliver dependable performance in industrial flow control applications. With a robust A216 WCB carbon steel body and raised face (RF) flanged connections, this valve features a bolted bonnet and a flexible wedge disc design, ensuring reliable shutoff and reduced seat wear. The disc is constructed from WCB and hard-faced with 13% chromium (13Cr) for increased durability and corrosion resistance. The seat rings are made of A105N carbon steel overlaid with STL.6 (Stellite), offering excellent wear resistance and sealing performance. The stem, crafted from A182 F6a stainless steel, enhances strength and galling resistance. Suitable for water, oil, gas, and steam services, this gate valve complies with industry-standard design and manufacturing codes for safe and long-lasting operation.

Specifications:

– Manufacturer: MT Group
– Valve Type: Gate Valve
– Size: 10 inches
– Pressure Class: ANSI Class 150
– End Connection: Raised Face (RF) Flanged
– Operation: Handwheel (HW)
– Bonnet Type: Bolted Bonnet
– Disc Type: Flexible Wedge
– Body Material: ASTM A216 WCB (Carbon Steel)
– Disc Material: ASTM A216 WCB with 13Cr Hardfacing
– Seat Material: ASTM A105N + STL.6 (Stellite Overlay)
– Stem Material: ASTM A182 F6a (13% Cr Stainless Steel)
– Design Standard: API 600
– Face-to-Face Standard: ASME B16.10
– Flange Standard: ASME B16.5
– Pressure-Temperature Rating: ASME B16.34

For further specifications or to inquire about this equipment and ReflowX's logistics services, Please contact ReflowX at info@reflowx.com
