MT Group Gate Valve – 12" Class 150 RF, Bolted Bonnet, WCB Body, A182 F6a Stem

The MT Group 12-inch Class 150 gate valve is a robust and dependable shutoff valve designed for medium-pressure industrial applications. Featuring a raised face (RF) flanged connection and bolted bonnet construction, this valve is built with a durable A216 WCB carbon steel body and a flexible wedge disc with 13Cr hardfacing for wear resistance. The seat is constructed from A105N carbon steel with STL.6 hardfacing, ensuring extended service life under challenging flow conditions. The stem, made from A182 F6a stainless steel, ensures excellent corrosion resistance and mechanical strength. This valve is well-suited for water, oil, and gas services in petrochemical, power generation, and general industrial systems where reliable flow control and tight shutoff are required.

Specifications:

– Manufacturer: MT Group
– Valve Type: Gate Valve
– Size: 12 inches
– Pressure Class: ANSI Class 150
– End Connection: Raised Face (RF) Flanged
– Operation: Handwheel (HW)
– Bonnet Type: Bolted Bonnet
– Disc Type: Flexible Wedge
– Body Material: ASTM A216 WCB (Carbon Steel)
– Disc Material: ASTM A216 WCB with 13Cr hardfacing
– Seat Material: ASTM A105N with STL.6 hardfacing
– Stem Material: ASTM A182 F6a (13% Cr Stainless Steel)
– Design Standards: API 600 / ASME B16.34
– Face-to-Face Dimension: ASME B16.10 compliant
– Flange Standard: ASME B16.5

For further specifications or to inquire about this equipment and ReflowX's logistics services, Please contact ReflowX at info@reflowx.com
