1/2" Gate Valve #800 – A105N, FNPT Ends, Trim 8, LVF Valves

The LVF 1/2" Gate Valve is a high-pressure, forged steel valve engineered for dependable isolation in demanding applications. Built to Class 800 pressure specifications, it features a robust A105N carbon steel body with Trim 8 internals, suitable for use in corrosive and sour service environments per NACE MR0103 and MR0175 standards. The valve design includes a rising stem (OS&Y), bolted bonnet (BB) for maintenance access, and threaded FNPT end connections. With its compact size and rugged handwheel operator, this valve is an excellent choice for upstream oil & gas, chemical, and high-pressure industrial pipeline systems.

Specifications:

– Valve Type: Gate Valve
– Size: 1/2 inch
– Pressure Class: Class 800
– Body Material: ASTM A105N (Forged Carbon Steel)
– Trim: Trim 8 (A105N + STL.6 hard-faced seating)
– Ends: FNPT – Female NPT Threaded Ends
– Stem Type: Rising Stem – OS & Y (Outside Screw and Yoke)
– Bonnet Type: Bolted Bonnet (BB)
– Operator: Manual Handwheel
– Design Standard: API 602 / ASME B16.34
– Thread Standard: ASME B1.20.1
– Compliance: NACE MR0103 / MR0175 (Sour Gas Service)
– Application: Isolation in high-pressure, corrosive environments
– Manufacturer: LVF Valves
