Gate Valve – 3" Class 150 RF, Bolted Bonnet, WCB Body, A182 F6a Stem - MT Group

The MT Group 3-inch gate valve is engineered for reliable shutoff performance in low- to medium-pressure industrial pipeline systems. This ANSI Class 150 valve features raised face (RF) flanged ends, a rugged bolted bonnet construction, and a flexible wedge disc for dependable sealing. The valve body is manufactured from ASTM A216 WCB carbon steel for strength and durability, while the disc is made of A217 CA15 stainless steel alloy for corrosion and wear resistance. The seat is constructed from A105N carbon steel with STL.6 (Stellite 6) overlay, offering extended life in abrasive or high-cycling environments. An A182 F6a stainless steel stem completes the assembly, providing excellent resistance to galling and corrosion. Commonly used in water, oil, steam, and general process lines, this gate valve meets key industry standards and ensures tight shutoff under a wide range of operating conditions.

Specifications:

– Manufacturer: MT Group
– Valve Type: Gate Valve
– Size: 3 inches
– Pressure Class: ANSI Class 150
– End Connection: Raised Face (RF) Flanged
– Operation: Handwheel (HW)
– Bonnet Type: Bolted Bonnet
– Disc Type: Flexible Wedge
– Body Material: ASTM A216 WCB (Carbon Steel)
– Disc Material: ASTM A217 CA15 (Stainless Steel Alloy)
– Seat Material: ASTM A105N + STL.6 (Stellite Overlay)
– Stem Material: ASTM A182 F6a (13Cr Stainless Steel)
– Design Standards: API 600 / ASME B16.34
– Face-to-Face Standard: ASME B16.10
– Flange Standard: ASME B16.5
– Application Areas: Oil & Gas, Water Works, Power Generation, Industrial Processing
