MT Group Gate Valve – 6" Class 150 RF, Bolted Bonnet, WCB Body, A182 F6a Stem

The MT Group 6-inch Class 150 gate valve is a robust shutoff valve engineered for efficient flow isolation in industrial pipelines. Constructed with a high-strength A216 WCB carbon steel body and featuring raised face flanged ends, this valve incorporates a bolted bonnet and a flexible wedge disc design. The disc is fabricated from WCB and hard-faced with 13% chromium (13Cr) for enhanced durability and corrosion resistance. The seat ring is made from A105N carbon steel with a Stellite 6 overlay to withstand high wear and provide a reliable sealing surface. An A182 F6a stem offers excellent mechanical strength and corrosion protection, ensuring smooth operation and long-term reliability. This valve is well-suited for use in water, oil, steam, and general-purpose service pipelines in the energy, chemical, and industrial sectors.

Specifications:

– Manufacturer: MT Group
– Valve Type: Gate Valve
– Size: 6 inches
– Pressure Class: ANSI Class 150
– End Connection: Raised Face (RF) Flanged
– Operation: Handwheel (HW)
– Bonnet Type: Bolted Bonnet
– Disc Type: Flexible Wedge
– Body Material: ASTM A216 WCB (Carbon Steel)
– Disc Material: ASTM A216 WCB with 13Cr hardfacing
– Seat Material: ASTM A105N + STL.6 (Stellite Overlay)
– Stem Material: ASTM A182 F6a (13% Cr Stainless Steel)
– Standards Compliance:
 • API 600 Design Standard
 • ASME B16.10 (Face-to-Face)
 • ASME B16.5 (Flanges)
 • ASME B16.34 (Pressure-Temperature Ratings)
