8" Gate Valve #150 – API 600, RF, A216 WCB Body – Neway

This 8" Gate Valve by Neway is designed and manufactured according to API 600 standards, providing durable and efficient flow isolation in pipelines. Constructed with a robust A216 WCB cast carbon steel body and bolted bonnet, it incorporates a stainless steel A182 stem and a hard-faced A105N+STL.6 trim for enhanced wear resistance and sealing. The valve uses a rising stem with outside screw and yoke (OS&Y) design and features a flanged RF (Raised Face) connection, making it ideal for applications in oil & gas, water treatment, chemical, and industrial systems. This gate valve ensures minimal pressure drop and tight shut-off in full open or closed positions.

Specifications:

– Valve Type: Gate Valve
– Size: 8 inch
– Pressure Rating: Class 150
– Design Standard: API 600
– Body Material: A216 WCB (Cast Carbon Steel)
– Trim Type: Trim 8 (A105N+STL.6)
– Stem Material: A182 (Stainless Steel)
– Seat/Disc Material: Hard-faced STL.6
– End Connection: Flanged, RF (Raised Face)
– Bonnet Type: Bolted Bonnet
– Stem Design: Rising stem, OS&Y
– Face-to-Face Dimension: ASME B16.10
– Flange Standard: ASME B16.5
– Temperature Rating: Standard for WCB class 150 valves
– Manufacturer: Neway Valve Co., Ltd.
– Application: Oil & gas, petrochemical, waterworks, power generation
