Resilient Seated Butterfly Valve – Series 3A/3AH, High-Pressure, Wafer/Lug Style

Product Details

Quantity

100
Availability (Lead Time)

6-10 Weeks
Product Location

United Arab Emirates
Condition
OEM

Bray International
Equipment code

CFIHOS-30000649

Get Quotation Whatsapp

Short Description

High-performance resilient seated butterfly valve Series 3A/3AH designed for high-pressure applications. Features include ductile iron body, resilient liner, and precision disc for reliable shut-off and throttling.

Description

Resilient Seated Butterfly Valve – Series 3A/3AH, High-Pressure, Wafer/Lug Style

The Resilient Seated Butterfly Valve Series 3A/3AH is engineered for superior performance in demanding water, HVAC, and industrial fluid systems. Available in wafer and lug body styles, the Series 3A/3AH provides tight shut-off in both directions and meets high-pressure requirements with robust construction and versatile installation compatibility.

This valve features a high-strength ductile iron body, resilient EPDM/NBR seat, and a precision-machined disc for smooth rotation and reduced torque. The stem-to-disc connection is secure and corrosion-resistant, enhancing the valve's longevity in corrosive and abrasive environments. It is suitable for on/off or modulating service and can be actuated manually or automatically.

Specifications:

– Valve Type: Resilient Seated Butterfly Valve
– Series: 3A (Wafer), 3AH (Lug)
– Size Range: 2" to 36" (DN50 to DN900)
– Pressure Rating: Up to 300 psi (20.7 bar)
– Body Style: Wafer and Lug
– Body Material: Ductile Iron (ASTM A536 Grade 65-45-12)
– Disc Material: Ductile Iron, Stainless Steel, Aluminum Bronze (optional coatings: Nylon, Epoxy)
– Seat/Liner Material: EPDM, NBR, Hypalon, Viton, others on request
– Shaft Material: Stainless Steel (AISI 410/416 or 316)
– Shaft Design: One-piece or two-piece blowout-proof
– End Connection: Flanged (conforms to ANSI 125/150, PN10/16)
– Face-to-Face: Complies with ISO 5752, API 609
– Temperature Range: -10°C to +120°C (material dependent)
– Design Standard: API 609, MSS SP-67
– Seat Type: Resilient, bubble-tight shut-off
– Leakage Rate: Zero leakage (bi-directional)
– Operation: Manual (lever/gear), Pneumatic, Electric
– Applications: HVAC, Water/Wastewater, Irrigation, Mining, Fire Protection, Chemical Processing

For further specifications or to inquire about this equipment and ReflowX's logistics services, Please contact ReflowX at info@reflowx.com
