MT Group 10" Trunnion Gear‑Operated Ball Valve – Class 600, WCB Body, F316 Trim

The MT Group 10" Class 600 Trunnion Gear‑Operated Ball Valve is a heavy‑duty industrial valve designed for high‑pressure fluid control applications. Built with a robust ASTM A216 WCB carbon steel body and precision‑engineered A182 F316 stainless steel ball, seat, and stem, this valve offers reliable performance and corrosion resistance. Its trunnion‑mounted design ensures reduced operating torque and improved sealing under pressure. The split‑body and side‑entry configuration allow for easier maintenance, and the gear-operated mechanism enables smooth and controlled actuation, making this valve ideal for critical oil & gas, refining, power, and process industry systems.

Specifications:

– Valve Type: Trunnion-mounted ball valve
– Operation: Gear-operated
– Size: 10 inch
– Pressure Class: 600#
– Body Material: ASTM A216 WCB (Carbon Steel)
– Ball Material: ASTM A182 F316 (Stainless Steel)
– Seat Material: ASTM A182 F316 (Stainless Steel)
– Stem Material: ASTM A182 F316 (Stainless Steel)
– Body Design: Split body, side entry
– End Connection: Raised-Face (RF) Flanged
– Face-to-Face: ASME B16.10
– Flange Standard: ASME B16.5
– Design Standard: API 6D / ASME B16.34
– Temperature Rating: As per ASME B16.34 Class 600
– Applications: Oil & gas pipelines, petrochemical plants, industrial utilities, power generation

For further specifications or to inquire about this equipment and ReflowX's logistics services, Please contact ReflowX at info@reflowx.com
