MT Group 4" Trunnion Gear‑Operated Ball Valve – Class 600, WCB Body, F316 Trim

Product Details

Quantity

2
Availability (Lead Time)

0-2 Weeks
Product Location

United Arab Emirates
Condition
OEM

MT GROUP
Equipment code

CFIHOS-30000649
Total Price
Per Unit Price

$ 1,065.00

Short Description

4‑inch Class 600 trunnion‑mounted ball valve with gear operator, split‑body ASTM A216 WCB carbon‑steel construction, and A182 F316 stainless‑steel ball, seat, and stem. Raised‑face flanged ends.

Description

MT Group 4" Trunnion Gear‑Operated Ball Valve – Class 600, WCB Body, F316 Trim

The MT Group 4" Class 600 Trunnion Gear‑Operated Ball Valve is engineered for robust performance in high‑pressure and high‑integrity piping systems. Its split‑body, side‑entry design enables easy in‑line maintenance and inspection. The valve body, forged from ASTM A216 WCB carbon steel, delivers exceptional mechanical strength, while the internal trim—ball, seat, and stem—is precision‑machined from corrosion‑resistant A182 F316 stainless steel. Raised‑face (RF) flanged ends ensure secure, leak‑free connections with ANSI B16.5 Class 600 piping. The integrated gear operator allows precise, quarter‑turn actuation with minimal effort, making it ideal for remote or automated control in oil & gas, petrochemical, power generation, and industrial utility applications.

Specifications:

– Valve Type: Trunnion‑mounted ball valve
– Operation: Gear‑operated (with manual override)
– Size: 4 inch
– Pressure Class: 600# (ANSI B16.5)
– Body Style: Split body, side entry
– Body Material: ASTM A216 WCB (Carbon Steel)
– Ball Material: ASTM A182 F316 (Stainless Steel)
– Seat Material: ASTM A182 F316 (Stainless Steel)
– Stem Material: ASTM A182 F316 (Stainless Steel)
– End Connections: Raised‑Face (RF) Flanged
– Face‑to‑Face: ASME B16.10
– Flange Standard: ASME B16.5
– Design Standards: API 6D / ASME B16.34
– Temperature Rating: Per ASME B16.34 for Class 600
– Applications: High‑pressure pipelines, petrochemical plants, power stations, water treatment, and industrial process lines

For further specifications or to inquire about this equipment and ReflowX's logistics services, Please contact ReflowX at info@reflowx.com
