MT Group 6" Trunnion Gear‑Operated Ball Valve – Class 150, WCB Body, F316 Trim

The MT Group 6" Class 150 Trunnion Gear‑Operated Ball Valve is engineered for reliable, low‑torque actuation in industrial piping systems. Its split‑body, side‑entry design allows easy in‑line maintenance. The valve body is forged from ASTM A216 WCB carbon steel for high strength, while the internal ball, seat, and stem are precision‑machined from A182 F316 stainless steel to resist corrosion and wear. A raised‑face (RF) flange connection ensures leak‑free integration with ANSI Class 150 pipe networks. The gear operator provides smooth, controlled quarter‑turn operation, making it suitable for remote or automated applications in oil & gas, petrochemical, power generation, and water treatment facilities.

Specifications:

– Valve Type: Trunnion‑mounted ball valve
– Operation: Gear‑operated, manual override
– Size: 6 inch
– Pressure Class: 150# (ANSI B16.5)
– Body Style: Split body, side entry
– Body Material: ASTM A216 WCB (Carbon Steel)
– Ball Material: ASTM A182 F316 (Stainless Steel)
– Seat Material: ASTM A182 F316 (Stainless Steel)
– Stem Material: ASTM A182 F316 (Stainless Steel)
– End Connections: Raised Face (RF) flanged
– Face‑to‑Face: ASME B16.10
– Flange Standard: ASME B16.5
– Design Standards: API 6D / ASME B16.34
– Temperature Rating: per ASME B16.34 for Class 150
– Applications: Oil & gas, petrochemical, power, water treatment, bulk chemical handling
