MT Group 8" Trunnion Gear‑Operated Ball Valve – Class 150, WCB Body, F316 Trim

The MT Group 8" Class 150 Trunnion Gear‑Operated Ball Valve offers robust, low‑torque actuation for large‑bore piping systems. Its split‑body, side‑entry design facilitates straightforward maintenance without disturbing the pipeline. Fabricated from ASTM A216 WCB carbon steel, the valve body delivers high mechanical strength, while the internal ball, seat, and stem—made from corrosion‑resistant A182 F316 stainless steel—ensure long service life in harsh environments. The raised‑face (RF) flanged ends conform to ANSI Class 150 standards for reliable, leak‑tight connections. The integrated gear operator allows precise, quarter‑turn operation, making this valve ideal for remote or automated control in oil & gas, petrochemical, power generation, water treatment, and chemical processing industries.

Specifications:

– Valve Type: Trunnion‑mounted ball valve
– Operation: Gear‑operated, manual override
– Size: 8 inch
– Pressure Class: 150# (ANSI B16.5)
– Body Style: Split body, side entry
– Body Material: ASTM A216 WCB (Carbon Steel)
– Ball Material: ASTM A182 F316 (Stainless Steel)
– Seat Material: ASTM A182 F316 (Stainless Steel)
– Stem Material: ASTM A182 F316 (Stainless Steel)
– End Connections: Raised Face (RF) flanged
– Face‑to‑Face: ASME B16.10
– Flange Standard: ASME B16.5
– Design Standards: API 6D / ASME B16.34
– Temperature Rating: per ASME B16.34 for Class 150
– Applications: Oil & gas, petrochemical, power plants, water treatment, chemical transfer

For further specifications or to inquire about this equipment and ReflowX's logistics services, Please contact ReflowX at info@reflowx.com
