MT Group 2" Trunnion Lever Operated Ball Valve – Class 150, WCB Body, F316 Trim
The MT Group 2" Class 150 Trunnion Lever Operated Ball Valve is engineered for reliable performance in high-integrity piping systems. Built with a split-body, side-entry design, this valve provides enhanced sealing and structural strength under moderate pressure conditions. The carbon steel A216 WCB body offers mechanical toughness, while the internal trim—including the ball, seat, and stem—is entirely made of corrosion-resistant A182 F316 stainless steel. Ideal for process control in chemical, oil & gas, and utility applications, this valve features Raised Face (RF) flanged ends for easy integration with ANSI Class 150 pipelines.
Specifications:
– Valve Type: Trunnion Mounted Ball Valve
– Operation: Manual Lever Operated
– Size: 2 inch
– Pressure Class: 150#
– Body Design: Split Body, Side Entry
– Body Material: ASTM A216 WCB (Carbon Steel)
– Ball Material: ASTM A182 F316 (Stainless Steel)
– Seat Material: ASTM A182 F316 (Stainless Steel)
– Stem Material: ASTM A182 F316 (Stainless Steel)
– End Connection: RF (Raised Face) Flanged
– Design Standards: API 6D / ASME B16.34 (typical)
– Face-to-Face: ASME B16.10
– Flange Dimensions: ASME B16.5
– Applications: Oil & gas, petrochemical, water, and general process control
