MT Group 3" Trunnion Lever Operated Ball Valve – Class 600, WCB Body, F316 Trim
The MT Group 3" Trunnion Lever Operated Ball Valve is a high-performance industrial valve engineered for reliable shut-off and flow control in high-pressure systems. Designed with a Class 600 pressure rating and a full bore configuration, this valve provides minimal flow resistance. Its robust split-body, side-entry design allows for easy maintenance and inspection. The body is fabricated from durable A216 WCB carbon steel, while the ball, seat, and stem are precision-machined from A182 F316 stainless steel for superior corrosion resistance. Raised Face (RF) flanged ends ensure compatibility with standard ASME B16.5 flanged piping systems. Suitable for critical service in oil & gas, petrochemical, and power generation sectors.
Specifications:
– Valve Type: Trunnion Mounted Ball Valve
– Size: 3 inch
– Pressure Class: 600#
– Operation: Lever Operated
– Body Type: Split Body, Side Entry
– Body Material: A216 WCB (Carbon Steel)
– Ball Material: A182 F316 (Stainless Steel)
– Seat Material: A182 F316 (Stainless Steel)
– Stem Material: A182 F316 (Stainless Steel)
– End Connections: Raised Face (RF) Flanged
– Design Standards: API 6D / ASME B16.34
– Flange Standard: ASME B16.5
– Face-to-Face: ASME B16.10
– Temperature Range: Depending on gasket and seat material
– Applications: High-pressure pipelines, hydrocarbon services, industrial process lines
For further specifications or to inquire about this equipment and ReflowX's logistics services, Please contact ReflowX at info@reflowx.com
