MT Group 3" Trunnion Lever Operated Ball Valve – Class 900, WCB Body, F316 Trim
The MT Group 3" Trunnion Lever Operated Ball Valve is a high-pressure, heavy-duty valve built for critical flow control applications. Featuring a Class 900 pressure rating and full bore design, this valve is ideal for energy, petrochemical, and high-integrity process systems. The body is constructed from A216 WCB carbon steel for structural strength, while the ball, seat, and stem are all made from A182 F316 stainless steel, providing exceptional corrosion resistance and operational reliability. The valve includes RTJ (Ring Type Joint) flanged ends, suitable for secure, leak-free connections in high-pressure pipelines. Its split-body, side-entry configuration allows easier access for maintenance and internal inspection.
Specifications:
– Valve Type: Trunnion Mounted Ball Valve
– Size: 3 inch
– Pressure Class: 900#
– Operation: Lever Operated
– Body Type: Split Body, Side Entry
– Body Material: A216 WCB (Carbon Steel)
– Ball Material: A182 F316 (Stainless Steel)
– Seat Material: A182 F316 (Stainless Steel)
– Stem Material: A182 F316 (Stainless Steel)
– End Connections: RTJ (Ring Type Joint) Flanged Ends
– Design Standards: API 6D / ASME B16.34
– Flange Standard: ASME B16.5
– Face-to-Face: ASME B16.10
– Temperature Range: Service-dependent
– Applications: High-pressure pipelines, offshore rigs, hydrocarbon process systems
For further specifications or to inquire about this equipment and ReflowX's logistics services, Please contact ReflowX at info@reflowx.com
