Product Description

The AQ-20 series air compressor safety valve is designed to provide overpressure protection for compressed air systems. The valve operates automatically when system pressure exceeds the allowable limit, releasing excess pressure to maintain safe operating conditions.

Once the system pressure returns to a predetermined level, the valve closes automatically, ensuring controlled and reliable operation. The design is suitable for air compressor applications and related equipment operating at temperatures up to 200°C.

The valve features a compact construction with threaded connection and integrated spring mechanism for pressure regulation.

Specifications

• Type: Air Compressor Safety Valve
• Model: AQ-20 Series
• Function: Overpressure Protection / Pressure Relief
• Operation: Spring Loaded, Automatic Open/Close
• Medium: Air
• Maximum Working Temperature: ≤ 200°C
• Connection Type: Threaded

Connection Sizes (as per available data)

• DN: 20 / 25
• Thread Type: G1" / M36 × 2
• Bolt Hole Configuration: 4-Ø17 / 4-Ø20
• Face-to-Face Length (L): 25 / 28 mm
• Height (H): 220 / 226 mm
