Product Description

The A46 series safety valve is a pilot operated type valve designed in accordance with American standard requirements for high temperature and high-pressure applications. The valve utilizes a pilot control system to regulate opening and closing, providing accurate pressure control and stable operation under varying system conditions.

When system pressure exceeds the preset limit, the pilot mechanism actuates the main valve to release excess pressure. Once the pressure returns to normal operating levels, the valve reseals, ensuring controlled and efficient performance.

The pilot operated design offers advantages such as improved sealing performance, reduced leakage, and higher set pressure accuracy compared to conventional spring-loaded valves. This makes the valve suitable for critical systems requiring precise pressure regulation.

The valve is designed for use with steam, air, and gas media and is constructed for integration into industrial pipeline systems operating under elevated temperature and pressure conditions.

Specifications

• Type: Pilot Operated Safety Valve
• Model: A46 Series
• Standard: American Standard
• Function: Overpressure Protection / Pressure Relief
• Operation: Pilot Controlled
• Service: High Temperature and High Pressure
• Medium: Steam, Air, Gas
• Connection Type: Flanged

Connection Sizes (as per available data)

• DN: Sizes available (not fully specified)
• Flanged Connection: Yes
