Starline Ball Valve – Type 209, PN 20 / Class 150, F51 Body, UNS S31600 Ball

ReflowX SKU: REF-7027

Product Details

Quantity

10
Availability (Lead Time)

0-2 Weeks
Product Location

United Arab Emirates
Condition

Surplus
OEM

ReflowX
Equipment code

Get Quotation Whatsapp

Short Description

High-performance Starline Type 209 Ball Valve, Class 150 / PN 20, with F51 body and UNS S31600 ball. Designed in compliance with EN12516 for industrial fluid control applications. Origin: Italy.

Description

Starline Ball Valve – Type 209, PN 20 / Class 150, F51 Body, UNS S31600 Ball

The Starline Type 209 3SV-G Ball Valve is a precision-engineered industrial valve manufactured in Bergamo, Italy. Designed for use in critical flow control environments, it offers reliable shutoff and control capabilities. The valve features a duplex stainless steel F51 body and a corrosion-resistant UNS S31600 stainless steel ball. With a pressure rating of PN 20 (Class 150) and a design pressure of 20 bar, this valve operates efficiently in systems with temperature ranges between –30°C to +220°C. Manufactured to EN12516 standards, this valve is suitable for applications in the chemical, petrochemical, and energy sectors. Its robust construction ensures long-term performance and safety under demanding conditions.

Specification:

– Product Type: Industrial Ball Valve
– Manufacturer: Starline S.p.A.
– Model/Type: 209 (3SV-G)
– Pressure Rating: PN 20
– Class: 150
– Design Pressure: 20 bar
– Temperature Range: -30°C to +220°C
– Body Material: F51 Duplex Stainless Steel
– Ball Material: UNS S31600 (AISI 316 Stainless Steel)
– Design Standard: EN12516
– Serial Number: 673660
– Connection Type: Threaded or flanged (depending on configuration)
– Applications: Petrochemical, power generation, offshore platforms, industrial pipelines
– Origin: Bergamo, Italy

For further specifications or to inquire about this equipment and ReflowX's logistics services, Please contact ReflowX at info@reflowx.com

Technical Details

ISO 15926 Pt 4	10554
Model Number	209 (3SV-G)
Manufacturer Name	Starline S.p.A.
Height	110 mm to 280 mm
Width	70 mm to 150 mm
Length	140 mm to 230 mm
Weight	4 kg to 18 kg
Color	Red
ISO 15926 Pt 4	10554
PCA RDS Code	RDS292589
CFIHOS ID	CFIHOS-30000660
IFC Class	IfcValve
Design Specification	2-piece Ball Valve
Failure Action	Fail-closed under pressure loss
Fluid Name	Hydrocarbons, Steam, Water, Hydrogen, Corrosive Chemicals, Brine, Natural Gas
Full Opening Valve	Yes
Nominal Diameter	DN15 to DN50
Normal Operating Pressure	290 PSI
Normal Operating Temperature	–30°C to +220°C
Piping Class	Class 150
UNSPSC Code	40141600
