VALVITALIA Check Valves – ½” to 24”, 150# to 1500#, WCB/F316L, RF/RTJ/SW Ends

ReflowX SKU: REF-1214

Product Details

Quantity

50
Availability (Lead Time)

0-2 Weeks
Product Location

United Arab Emirates
Condition

New
OEM

VALVITALIA VALVES, ITALY
Equipment code

Get Quotation Whatsapp

Short Description

High-performance VALVITALIA check valves, sizes ½” to 24”, pressure classes 150# to 1500#, with WCB, A105N, F316L, and LCC bodies. Available in RF, RTJ, NPT, SW, and LRF ends with reduced or full bore.

Description

VALVITALIA Check Valves – ½” to 24”, 150# to 1500#, WCB/F316L, RF/RTJ/SW Ends
Description:

VALVITALIA check valves are engineered to prevent backflow in critical flow systems across oil & gas, petrochemical, power, and marine sectors. Available in sizes from ½” to 24” and pressure classes ranging from 150# to 1500#, these valves feature durable construction using materials such as WCB, A105N, F316L, and LCC. Customers can select from reduced bore (RD) or full bore (FB) designs based on flow and pressure drop requirements. The valves are manufactured with multiple end connection types including Raised Face (RF), Ring Type Joint (RTJ), Large Raised Face (LRF), Socket Weld (SW), and Threaded (NPT), providing flexibility for various piping systems. Designed in accordance with major international standards, VALVITALIA check valves offer high sealing integrity and long service life in demanding conditions.

Specifications:

– Manufacturer: VALVITALIA, Italy
– Valve Type: Check Valve
– Size Range: ½” to 24”
– Pressure Ratings: 150#, 300#, 600#, 800#, 900#, 1500#
– Body Materials:
• WCB (Carbon Steel)
• A105N (Forged Carbon Steel)
• F316L (Stainless Steel)
• LCC (Low Temp Carbon Steel)
– Bore Options:
• Reduced Bore (RD)
• Full Bore (FB)
– End Connections:
• RF – Raised Face
• RTJ – Ring Type Joint
• LRF – Large Raised Face
• NPT – Threaded
• SW – Socket Weld
– Design Standards: API / ANSI / ASME (specific model-dependent)
– Testing & Marking: In accordance with industry standards
– Applications:
• Oil & Gas Transmission
• Petrochemical Plants
• Power Generation
• Refinery and Industrial Pipelines
• Marine Systems
For further specifications or to inquire about this equipment and ReflowX's logistics services, Please contact ReflowX at info@reflowx.com

Technical Details

ISO 15926 Pt 4	10554
Model Number	Check Valve
Manufacturer Name	VALVITALIA, Italy
Height	100 mm to 1200 mm
Width	100 mm to 900 mm
Length	½" Class 150: ~108 mm, 24" Class 150: ~787 mm, 24" Class 1500: ~1100+ mm
Weight	6 kg (½”) to ~2000+ kg (24” 1500#)
ISO 15926 Pt 4	10554
PCA RDS Code	RDS292589
CFIHOS ID	CFIHOS-30000660
IFC Class	IfcValve
Design Specification	API 6D, BS 1868, API 594, and ASME B16.34
Failure Action	Non-return (self-actuated)
Fluid Name	Hydrocarbons, Steam, Air, Water, Chemicals, Brine, Inert gases
Full Opening Valve	Optional – Full bore (FB) models available
Nominal Diameter	½” to 24”
Normal Operating Pressure	19 bar to 250 bar
Normal Operating Temperature	29°C to +200°C
Piping Class	ASME B31.3
UNSPSC Code	40141600
