VALVITALIA Globe Valves – ½” to 8”, 150# to 1500#, Industrial Service

ReflowX SKU: REF-7503

Product Details

Quantity

50
Availability (Lead Time)

0-2 Weeks
Product Location

United Arab Emirates
Condition

New
OEM

VALVITALIA VALVES, ITALY
Equipment code

Get Quotation Whatsapp

Short Description

VALVITALIA forged and cast steel globe valves, sizes ½” to 8”, available in pressure classes 150# to 1500#, designed for precise flow regulation in demanding energy and industrial systems.

Description

VALVITALIA Globe Valves – ½” to 8”, 150# to 1500#, Industrial Service
Description:

VALVITALIA globe valves are precision-engineered flow control solutions used across power generation, oil & gas, marine, and civil infrastructure sectors. Manufactured in sizes from ½” to 8”, and pressure classes from 150# to 1500#, these globe valves ensure high reliability in throttling and isolation applications. Designed with robust forged or cast steel construction, these valves feature a rising stem, bolted bonnet design, and options for socket weld, threaded, or flanged end connections. All VALVITALIA globe valves comply with international standards such as API, ANSI, and ASME, and are pressure tested to ensure performance under critical service conditions. Their high-integrity sealing systems and optional fire-safe design make them suitable for severe service across industrial piping networks.

Specifications:

– Manufacturer: VALVITALIA, Italy
– Valve Type: Globe Valve
– Size Range: ½” to 8”
– Pressure Ratings: 150#, 300#, 600#, 800#, 900#, 1500#
– Design Standards: API 602 / API 623, ANSI B16.34, ASME
– Body Materials: Forged Steel / Cast Steel (WCB, F316L, LF2 – confirm per specification)
– End Connections:
• Flanged (ANSI B16.5)
• Socket Weld (ASME B16.11)
• Threaded/NPT (ASME B1.20.1)
– Bonnet Type: Bolted Bonnet (standard) – Pressure Seal optional
– Stem Configuration: Rising stem, Outside Screw & Yoke (OS&Y)
– Packing: Graphite or PTFE with self-aligning gland
– Seat Type: Renewable or integral (hard-faced optional)
– Backseat: Integral
– Testing Standard: API 598
– Marking: MSS SP-25
– Applications:
• Oil & Gas
• Petrochemical
• Power Plants
• Refining & Process Industry
• Marine Systems
For further specifications or to inquire about this equipment and ReflowX's logistics services, Please contact ReflowX at info@reflowx.com

Technical Details

ISO 15926 Pt 4	10554
Model Number	Globe Valve
Manufacturer Name	VALVITALIA, Italy
Height	180 mm (½” Class 150) to 1100 mm (8” Class 1500)
Width	100 mm to 450 mm
Length	½" Class 150: ~108 mm, 8" Class 150: ~419 mm, 8" Class 1500: ~610 mm
Weight	5 kg (½”) up to ~550 kg (8” 1500#)
ISO 15926 Pt 4	10554
PCA RDS Code	RDS292589
CFIHOS ID	CFIHOS-30000660
IFC Class	IfcValve
Failure Action	Manual globe valves fail-in-place
Fluid Name	Hydrocarbons, Steam, Water, Condensate, Process chemicals and inert gases
Full Opening Valve	No – Globe valves are not full port by design
Nominal Diameter	½” to 8” (DN15 to DN200)
Normal Operating Temperature	-29°C to +200°C
Piping Class	ASME B31.3
UNSPSC Code	40141600
