VALVITALIA Italy Ball Valves – ½” to 24”, 150# to 6000#, Industrial Class

ReflowX SKU: REF-0

Product Details

Quantity

50
Availability (Lead Time)

0-2 Weeks
Product Location

United Arab Emirates
Condition

New
OEM

VALVITALIA VALVES, ITALY
Equipment code

Get Quotation Whatsapp

Short Description

High-performance ball valves from VALVITALIA Italy, available in ½” to 24” sizes and pressure classes 150# to 6000#. Designed for critical applications in energy, marine, and civil industries.

Description

VALVITALIA Italy Ball Valves – ½” to 24”, 150# to 6000#, Industrial Class
Description:

VALVITALIA Italy offers a robust line of ball valves designed for the highest standards in energy, marine, and civil infrastructure applications. Ranging in size from ½” to 24”, these valves are built to operate under demanding pressure conditions, with pressure class ratings from 150# up to 6000#. Engineered with precision and reliability, VALVITALIA ball valves are suitable for high-pressure, high-temperature environments and are trusted globally across power plants, petrochemical installations, offshore platforms, and industrial pipelines. Manufactured with advanced metallurgy and quality-controlled processes, these valves offer excellent sealing, low-torque operation, and long service life. As part of VALVITALIA's broad product portfolio, these ball valves are complemented by actuators, flanges, isolation joints, and fire safety components.

Specifications:

– Manufacturer: VALVITALIA Group, Italy
– Valve Type: Ball Valve
– Size Range: ½” to 24”
– Pressure Ratings: 150#, 300#, 600#, 800#, 900#, 1500#, 2500#, 6000#
– Construction Standards: API, ASME, ANSI
– Body Material Options: (Typically includes WCB, A105N, F316L, LF2 – specify on order)
– End Connections: RF, RTJ, NPT, SW, BW (varies by model)
– Bore Options: Full Bore (FB) and Reduced Bore (RB)
– Design Features:
– Fire-safe certified (optional)
– Anti-blowout stem
– Low emission and ISO/API-certified sealing
– Available with manual, electric, or pneumatic actuators
– Applications:
– Oil & Gas
– Power Generation
– Marine & Offshore
– Civil and Industrial Pipelines
– Process Industries

For further specifications or to inquire about this equipment and ReflowX's logistics services, Please contact ReflowX at info@reflowx.com

Technical Details

ISO 15926 Pt 4	10554
Model Number	Ball Valve
Manufacturer Name	VALVITALIA Group, Italy
Height	150 mm (½" 150#) to ~1300 mm (24" 600#)
Width	100 mm to over 1000 mm (manual to actuated)
Length	140 mm (2” 150#) up to ~1800 mm (24” 600# full bore)
Weight	5 kg (½” 150#) to 2,800+ kg (24” 600# forged full bore with actuator)
ISO 15926 Pt 4	10554
PCA RDS Code	RDS292589
CFIHOS ID	CFIHOS-30000660
IFC Class	IfcValve
Design Specification	API 6D / API 608
Failure Action	Spring-return actuator configuration enables fail-open or fail-close as required
Fluid Name	Suitable for Oil, Gas, Steam, Water, Chemicals, and Corrosive Fluids
Full Opening Valve	Full Bore (FB) and Reduced Bore (RB) versions
Nominal Diameter	½” to 24” (DN15 to DN600)
Normal Operating Pressure	ANSI Class 150 to 6000 (up to 413 bar)
Normal Operating Temperature	-46°C to +200°C
Piping Class	ASME B31.3 / B31.1 piping systems
UNSPSC Code	40141600
