NSW 1” Y-Pattern Forged Flanged Globe Valve – Class 800, A105 Body, F316 Trim

Product Details

Quantity

500
Availability (Lead Time)

4-6 Weeks
Product Location

China
Condition
OEM

WENZHOU NEWSWAY VALVE CO. LTD
Equipment code

Get Quotation Whatsapp

Short Description

1-inch Class 800 Y-type globe valve with flanged ends, forged A105 carbon steel body, A182 F316 stainless steel trim, bolted bonnet, rising stem, and API 602 design.

Description

NSW 1” Y-Pattern Forged Flanged Globe Valve – Class 800, A105 Body, F316 Trim

The NSW 1" Y-Pattern Forged Globe Valve – Class 800 is a compact and durable flow control solution designed for precise throttling and shut-off under high pressure. Engineered to API 602 standards, the forged steel construction ensures high mechanical strength, leak-tight operation, and long service life.

This valve features a Y-type body design that reduces pressure loss compared to conventional globe valves and is ideal for directional flow regulation. It is equipped with an outside screw and yoke, rising stem, and integral backseat for reliable shut-off. The forged body is available in A105 carbon steel or stainless grades such as F316/F316L and Duplex steels for improved corrosion resistance. The self-sealing bonnet design further enhances pressure integrity.

Suited for applications in oil & gas, chemical, power, and general industry systems, the NSW Y-Globe Valve is available with a variety of end connections, including flanged, socket weld, butt weld, or screwed ends. The valve is fire-safe tested and can be supplied per NACE and ISO fugitive emission standards.

Specifications:

– Valve Type: Y-Pattern Globe Valve
– Operation: Manual handwheel (non-rising handwheel optional)
– Size Range: NPS 1/2 to NPS 2 (DN15 to DN50)
– Pressure Class: Class 800, Class 150 to Class 2500
– Body Material: Forged A105 (Optional: A182 F304, F304L, F316, F316L, F51, F53, A350 LF2, LF3, LF5)
– Trim Material: ASTM A182 F316 (standard); other trims available
– Bonnet Type: Bolted, Welded, or Pressure-Sealed Bonnet
– Design Standard: API 602, ASME B16.34, BS 5352
– Face-to-Face: Manufacturer's Standard
– End Connections:
• Flanged Ends to ASME B16.5
• Socket Weld Ends to ASME B16.11
• Butt Weld Ends to ASME B16.25
• Screwed Ends to ANSI/ASME B1.20.1
– Stem Design: Rising Stem, Outside Screw & Yoke (OS&Y)
– Gasket: Spiral Wound Gasket
– Seat: Renewable Seat Rings
– Disc Type: Solid Wedge
– Test Standard: API 598
– Fire Safe Design: API 6FA, API 607
– Certifications: NACE MR-0175, NACE MR-0103, ISO 15848
– Non-Destructive Testing: PMI, UT, RT, PT, MT
– Temperature Range: As per class and material

For further specifications or to inquire about this equipment and ReflowX's logistics services, Please contact ReflowX at info@reflowx.com
